PRODUCT DESCRIPTION
Electrically-assisted bike technical features
F
A
Battery
Battery unlocking cylinder
B
Controller and motor
C
Control screen
D
General operation of the electrical assistance
The electric bicycle can be used with or without assistance by pressing the ON/OFF button and playing around
with modes 1 / 2 / 3 / 4 / AUTO. Assistance modes modes 1 / 2 / 3 / 4 / AUTO, which you can select via the
«D» screen, let you select a level of electrical assistance in addition to the effort you put in. The electrical as-
sistance will only work if you pedal with the screen switched on and if one of the 4 modes has been selected.
Assistance cuts off when the speed is above 25km/h. During intensive use and in exceptional weather condi-
tions, the pedal-assist mode may cut out to safeguard the system. The power supplied is calculated by the "C"
controller according to the selected mode. According to the mode selected, the controller «C» sends more or
less current to the motor «C» to provide you with the desired level of assistance.
The electrical assistance does not work or shuts down in the following situations:
- The speed is above 25km/h (+/-10%)
- You're not pedalling
- The remaining charge in the battery is not sufficient
- When the control screen is turned off or unplugged
The electrical assistance may also cut out to protect the system in the event of intensive use and in exceptio-
nal weather conditions
C
A
Assistance mode control
E
Speed sensor
F
6
D
E
B
