Cleaning tool
1. The cleaning tool is located
above the dust box.
Cleaning
brush
Maintenance of roller brush (weekly
cleaning recommended)
1. Turn the main unit upside
down, keep your hand at the
upper notch of the roller
brush cover, then press
down to remove the cover
and pull it out, and lift the
right side of the roller brush
to remove it.
EN-25
2. Use method of cleaning
brush:
Cut the hair on the roller
①
brush with the blade.
Brush away the cut hair
②
with the fair brush.
Blade
Fair brush
2. Clean the roller brush and its
cover with a cleaning brush
or soft cloth.
3. Wash the roller brush with
water and dry it.
End cover
4. After completion of the cleaning,
push the end cover back to the
brush body.
5. Install the brush body in the
brush chamber in the direction as
illustrated.
6. Push and snap the roller brush
cover to the robot.
Cleaning of wheels (weekly cleaning
recommended)
Turn the drive wheels forward and backwards to remove foreign
matters from them. Clean them with the cleaning tool or soft
cloth and remove hair or foreign matters.
Cleaning of side brushes (weekly cleaning
recommended)
1.
Remove side brushes.
2. Dispose of dust adhered to the side brushes.
EN-26
