DAILY MAINTENANCE AND
SERVICE
Maintenance of dust box (cleanup as required)
1. Remove the dust box:
Pinch the dust box with
your two fingers, and
press the dust box
release key with another
hand to remove the box.
Dust-box
release key
3. Remove the filter
assembly according to
text prompts on the filter
assembly.
Filter assembly
5. Clean dust from the dust
collection port of the
dust box.
EN-23
2. Dust removal: open the
dust box, and remove dust
from the box.
4. Clean the dust box, filter
assembly, and filter cotton;
after cleaning and drying
completely, re-install them,
and close the rear cover,
check whether it is installed
in place; (Both of the dust
box and the filter assembly
can be washed with water).
Dust box Filter Filter assembly
cotton
Dry in the air
Maintenance of vibration mopping
assembly (weekly cleaning recommended)
1. Press the button on tank
and pull to remove.
Water Tank
3. Pull o the water
inlet/outlet plug from the
tank to drain all water in
the tank; wipe the tank
surface with a piece of
clean rag, not cleaning the
vibration tank with water.
Water
inlet/outlet
5. Dry the vibration mopping
assembly and the special
rag for vibration mopping.
EN-24
2. For vibration tank, please
note that the pad cannot
be removed, just remove
mop cloth, and wash it
for next use.
4. Clean the rag.
6. Clean up water scales
regularly according to
operating instructions. Fill the
tank with water to the MAX
line, add 5g citric acid to soak
for 30 minutes, then pour out
the water and clean again with
new water.
Repeat the above cleaning
procedures for heavy scales.
During the cleaning, do not
energize the tank.
