STROKE PROGRAMMING
Press OPEN button, bring the door to the desired opening and adjust the opening limit switch.
•
Press CLOSE button, bring the door to the closure. (NOTE : If connected, adjust the closure limit switch)
•
Press PROG button for 2 seconds, LED blinks.
•
Give a START impulse from button or radio transmitter, the door starts opening fast
•
Give a second START imulse when you want to start the slowing down in opening, the door stops once arrived to the opening
•
limit switch.
With automatic closure inserted, wait the desired time with the door open.
•
Give a START impulse, door begins to fast close
•
Give a second impulse when you want to start the slowing down in closing
•
Once arrived in closure the door memorizes the closed position.
•
SAFETY DEVICES FUNCTION
PHOTOCELL (terminal 2-4)
Occupancy of photocell causes :
Opening : no effect
•
Closing : immediate stop and return to the opening operation.
•
AMPERO-STOP FUNCTION
Opening :
Blocking the movement of the door
•
Closing :
Block ing and reverse in opening the movement of the door
•
START COMMAND FUNCTION
A START impluse by button or radio transmitter, with closed door, has the following function:
STEP BY STEP: OPEN → STOP → CLOSE → STOP → OPEN
•
AUTOMATIC: OPEN → STOP → AUTOMATIC CLOSURE O CLOSURE WITH IMPULSE → STOP → OPEN
•
-
WITHOUT SLOW DOWN IN START CLOSING (DIP SWITCH 7 OFF)
