6.3 SPOT WELDING OPERA TION

- Set spot welding operation by pressing button .
- Press button until LED lights up. Use knob
- Press the torch or spool gun button and start welding. It will stop automatically after
the pre-set time.
- See also Fig. N for directions relating to the procedure.

6.4 OVERLOAD PROTECTION

The thermostatic protection LED
display shows the message ALL thr) and cuts off the power supply; the system is reset
automatically after a few minutes' cooling.

6.5 PROGRAMMING THE WELDING PARAMETERS

The DEFAUL T values for the accessory welding parameters (slope up, burn-back time,
pre-gas time) are preset by the manufacturer; to customise each parameter proceed
as follows:
- Press button for at least 3 seconds until the message "nor" appears on the display .
- Press button until the LED (
accessory parameter to be programmed.
- Turn knob to modify the value of the selected parameter.
Wire feed rate slope up:
Adjustment range nor, r_1, ..., r_9 (nor = start without slope, r_1 = very quick start,
r_9 = very slow start).
Burn-back time:
Adjustment range 0-1sec.
Post-gas time:
Adjustment range 0-3sec.
- To restore the factory (default) setting press buttons
seconds.
- To store the defined value and exit programming mode, press button
least 3 seconds.
6.6 RESETTING ALL PARAMETERS TO THE DEF AULT VALUES
Pressing buttons and simultaneously (not in programming mode) will restore all
welding parameters to their default values.

7. MAINTENANCE

WARNING! BEFORE CARRYING OUT MAINTENANCE OPERATIONS MAKE
SURE THE WELDING MACHINE IS SWITCHED OFF AND DISCONNECTED FROM
THE MAIN POWER SUPPLY.

7.1 ROUTINE MAINTENANCE:

ROUTINE MAINTENANCE OPERATIONS CAN BE CARRIED OUT BY THE
OPERATOR.
Torc h
- Do not put the torch or its cable on hot pieces; this would cause the insulating
materials to melt, making the torch unusable after a very short time;
- Make regular checks on the gas pipe and connector seals;
- Every time the wire reel is changed, blow out the wire-guide hose using dry
compressed air (max. 5 bar) to make sure it is not damaged;
- Before every use, check the wear and correct assembly of the parts at the end of
the torch: nozzle, contact tip, gas diffuser.

Wire feeder

- Make frequent checks on the state of wear of the wire feeder rollers, regularly
remove the metal dust deposited in the feeder area (rollers and wire-guide infeed
and outfeed).

7.2 EXTRAORDINARY MAINTENANCE:

EXTRAORDINARY MAINTENANCE OPERATIONS SHOULD BE CARRIED OUT
ONLY AND EXCLUSIVEL Y BY SKILLED OR AUTHORISED ELECTRICAL-
MECHANICAL TECHNICIANS.
__________________________________________________________________
WARNING! BEFORE REMOVING THE WELDING MACHINE PANELS AND
WORKING INSIDE THE MACHINE MAKE SURE THE WELDING MACHINE IS
SWITCHED OFF AND DISCONNECTED FROM THE MAIN POWER SUPPLY
OUTLET.
__________________________________________________________________
If checks are made inside the welding machine while it is live, this may cause
serious electric shock due to direct contact with live parts and/or injury due to
direct contact with moving parts.
- Inspect the welding machine regularly, with a frequency depending on use and the
dustiness of the environment, and remove the dust deposited on the transformer,
reactance and rectifier using a jet of dry compressed air (max. 10 bar).
- Do not direct the jet of compressed air on the electronic boards; these can be
cleaned with a very soft brush or suitable solvents.
- At the same time make sure the electrical connections are tight and check the
wiring for damage to the insulation.
- At the end of these operations re-assemble the panels of the welding machine and
screw the fastening screws right down.
- Never, ever carry out welding operations while the welding machine is open.
Fig. C
to set spot duration.
Fig. C
lights up when there is overheating (also, the
Fig. C
or or ) lights up for the corresponding
and simultaneously for 3
again for at
Fig. C
