9 TRUESET FLOATING HEAD REEL ADJUSTMENTS
9.9

REEL ASSEMBLY REMOVAL________________________________________________

The reel assembly can be removed for maintenance or to
use a different reel.
1. Remove hairpin and washer and slide the lift hangers
off the pins.
2. Disconnect motor electrical connectors and reel
ground wire. Whenever the reel motors are
disconnected from
connectors on the motor to prevent debris from
entering motor.
3. Remove hairpin and flat washer and lift panhard rod
off of reel bolt.
en-46
the harness, cover
Gen-Set Power Modules: Before tipping mower
back for adjustments, the fuel lever must be moved to
the OFF position to prevent fuel from leaking into the
crankcase. Do not leave the mower tipped back for
an extended length of time or oil may migrate into the
the
combustion chamber.
4. Tip the unit back onto the handle and slide the reel
away from the mower.
5. Reel assembly is reverse of removal.
NOTICE
