21.1 Electrical Schematic

Engine Control
(Hybrid Genset)
Brn
T1
Ignition
Coil
E1
Spark
Plug
SW3
Off
Engine
On/Off
On
Switch
Blk
Start
Run
Off
Red/Wht
B
Blk E
Red
Red Blk
R3
5Ω
Resistor
Red/Wht
R2
Bail
Potentiometer
Blk/Grn
Grn
Red/Grn
104
B2
Blk
J22
F1
50A
B4
U
Blk
J24
G
SW2
Key
Switch
D Red
Red
A Wht/Red Wht/Red
Blk
F Blk Blk
GC1
Red
SW1
Off
Mow
On
Switch
2 Yel Yel
3
Red/Wht
Red/Grn
Grn
Blk/Grn
Red/Blu
Grn/Blu
Blk/Blu
Shld
Blk/Blu
R1
Grn/Blu Throttle
Potentiometer
Red/Blu
Battery Pack
B1
(Battery)
P
U4
Battery Gauge
Key
N
B3
U3
1kW
Generator
Generator
(Hybrid Genset)
+48V Traction Motor
+48V Reel Motor
+48V Input
J2-25
Key-Ignition
J2-24
Key-Start
J2-26
Traction Motor Tach
MCU Gnd
Traction Motor Temp
J2-33
Resistor Gnd
Traction Motor Speed
Traction Motor Dir
J2-34 Traction Motor Enable
Resistor +Ref
Traction Motor Gnd
J2-35
Resistor -Ref
U5
MCU
Controller
J2-14
Mow Enable Input
J2-13
+15V Output
Reel Motor Tach
Reel Motor Temp
J2-31
Bail Pot +5V
Reel Motor Speed
J2-32
Bail Pot Wiper
Reel Motor Dir
J2-30
Bail Pot –
Reel Motor Enable
Reel Motor Gnd
J2-15
Throttle Pot +5V
J2-16
Throttle Pot Wiper
J2-28
Throttle Pot –
J2-27
CAN High
Throttle Pot Shieldg
CAN Low
CAN Shield
Red
J23- +
Blk
J23- –
F2
30A
Red Red/Yel Red
J23- +
Blk Blk
J23- –
Red/Blu
J1-2 Red
J1-1 Red
J1-3 Red/Blu
J2-6 Brn
J2-11 Red
J2-5 Grn
J2-20 Blu
J2-19 Wht
J2-4 Blk
J2-17 Brn
J2-12 Red
J2-21 Grn
J2-9 Blu
J2-8 Wht
J2-10 Blk
J2-1 Red
J2-2 Blk
J2-3 Shld
