Cerabar S PMC71, PMP71, PMP75 con FOUNDATION Fieldbus
Nombre del parámetro,
opción "Symbolic name"
MEASURED_TEMPERATURE
MEASURED_TEMPERATURE_UNIT
DEVICE_DIALOG
SW_LOCK
STATUS_LOCKING
LINEARIZATION
SCALE_IN
SCALE_OUT
DAMPING_VALUE
ZERO_POSITION_ADJUST
POSITION_INPUT_VALUE
CALIBRATION_OFFSET
CUSTOMER_UNIT_PRESSURE
CUSTOMER_FACTOR_UNIT_PRESS
LOW_TRIM_MEASURED
HIGH_TRIM_MEASURED
LEVEL_MODE
LINEAR_MEASURAND
LINEARIZED_MEASURAND
COMBINED_MEASURAND
DENSITY_UNIT
HEIGHT_UNIT
CUSTOMER_HEIGHT_UNIT
CUSTOMER_UNIT_FACTOR_HEIGHT
VOLUME_UNIT
CUSTOMER_UNIT_VOLUME
CUSTOMER_UNIT_FACTOR_VOLUME
MASS_UNIT
CUSTOMER_UNIT_MASS
CUSTOMER_UNIT_FACTOR_MASS
CALIBRATION_MODE
ADJUST_DENSITY
ZERO_POSITION
EMPTY_CALIBRATION
FULL_CALIBRATION
TANK_VOLUME
TANK_HEIGHT
HUNDRED_PERCENT_VALUE
LEVEL_MIN
LEVEL_MAX
PROCESS_DENSITY
LINEARIZATION_TABLE_SELECTION
LINEARIZATION_EDIT_MODE
LINEARIZATION_TABLE_PRE_EDIT
LINEARIZATION_TABLE_INDEX
LINEARIZATION_TABLE_X_VALUE
LINEARIZATION_TABLE_Y_VALUE
LINEARIZATION_TABLE_POST_EDIT
LINEARIZATION_TABLE_POST_VIEW
LEVEL_TANK_DESCRIPTION
SENSOR_PRESSURE
PRESSURE
Endress+Hauser
Pressure Transducer Block
Nombre del Índice Tipo de
parámetro, dato
opción "Label"
Temperature 32 DS-65
Temp. eng. unit 33 Unsigned16
Device dialog 34 Unsigned8
INSERT PIN No. 35 Unsigned16
Status locking 36 Unsigned16
Linearization 37 Unsigned8
Scale In 38 DS-68
Scale Out 39 DS-68
Damping value 40 Float
Pos. zero adjust 41 Unsigned8
Pos. input value 42 Float
Calib. offset 43 Float
Customer unit P 44 Visible String 8
Cust. unit. fact. P 45 Float
Lo trim measured 46 Float
Hi trim measured 47 Float
Level mode 48 Unsigned8
Lin. measurand 49 Unsigned8
Lin. measurand 50 Unsigned8
Comb. measurand 51 Unsigned8
Density unit 52 Unsigned16
Height unit 53 Unsigned16
Customer unit H 54 Visible String 8
Cust. unit. fact. H 55 Float
Volume unit 56 Unsigned16
Customer unit V 57 Visible String 8
Cust. unit. fact. V 58 Float
Mass unit 59 Unsigned16
Customer unit M 60 Visible String 8
Cust. unit. fact. M 61 Float
Calibration mode 62 Unsigned8
Adjust density 63 Float
Zero position 64 Float
Empty calibration 65 Float
Full calibration 66 Float
Tank volume 67 Float
Tank height 68 Float
100% point 69 Float
Level Min. 70 Float
Level Max. 71 Float
Process density 72 Float
Table selection 73 Unsigned8
Edit table 74 Unsigned8
Table editor 75 Unsigned8
Line numb: 76 Unsigned8
Valor x: 77 Float
Y-value: 78 Float
Table editor 79 Unsigned8
Measuring table 80 Unsigned8
Tank description 81 Visible String 32
Sensor pressure 82 Float
Pressure 83 Float
Tamaño Clase de Lec-
(bytes) almacena- tura
miento
5 D x
2 S x
1 D x
2 S x
2 D x
2 S x
11 S x
11 S x
4 S x
1 D x
4 S x
4 S x
S x
4 S x
4 S x
4 S x
1 S x
1 S x
1 S x
1 S x
2 S x
2 S x
S x
4 S x
2 S x
S x
4 S x
2 S x
S x
8 S x
1 S x
4 S x
4 S x
4 S x
4 S x
4 S x
4 S x
4 S x
4 S x
4 S x
4 S x
1 S x
1 S x
1 D x
1 D x
4 S x
4 S x
1 D x
1 D x
S x
4 D x
4 D x
Configuración
Escri- MODE_BLK Códigos de
tura reset
x OOS
x AUTO, OOS, 7864, 333
MAN
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS
x OOS 7864, 333,
2509
x OOS 7864, 333,
2509
x AUTO, OOS, 7864
MAN
x OOS 7864
2509
2509
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x AUTO, OOS, 7864
MAN
x OOS 7864
x OOS 7864, 333
x AUTO, OOS, 7864
MAN
x OOS 7864
x OOS 7864, 333
x AUTO, OOS, 7864
MAN
x OOS 7864
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x OOS 7864, 333
x AUTO, OOS, 7864, 333
MAN
x AUTO, OOS, 7864
MAN
x AUTO, OOS,
MAN
x AUTO, OOS,
MAN
x AUTO, OOS, 7864
MAN
x AUTO, OOS, 7864
MAN
x OOS
x AUTO, OOS,
MAN
x AUTO, OOS, 7864
MAN
