810 Filter compensation mode
2)
890 Sine filter inductivity
2)
891 Sine filter capacity
2)
1063 Line choke inductivity
1)
NOTE
In the KP500 control unit, parameter numbers > 999 are shown in hexadecimal form (999, A00 ... B5
... C66).
1) Parameter is active both in configuration 710 and 711
2) Parameter active in configuration 710 only
4.4.1.2 Actual value parameter
No.
213 Active power
2)
811 relative short-circuit voltage
1)
850 Frequency
2)
852 Mains current
1)
853 Mains voltage
2)
854 Active power
1)
863 Current a
2)
864 Current b
2)
865 Current c
2)
NOTE
In the KP500 control unit, parameter numbers > 999 are shown in hexadecimal form (999, A00 ... B5
... C66).
1) Parameter is active both in configuration 710 and 711
2) Parameter active in configuration 710 only
06/13
AEC-relevant parameters
Description
Quick Start Guide AEC
mH Phase inductivity of sine filter
µF Sine filter capacity per phase
mH Phase inductivity of line choke
Unit Description
Current effective power, consumed or
kW fed by the inverter from/into mains;
actual value parameter
Describes the total longitudinal
inductivity of the inductive components
%
across the voltage drop, referred to the
phase voltage in a 400 V mains
Hz Measured mains frequency
A Actual mains current value
V Calculated mains voltage
Current effective power, fed into the
kW mains by the inverter in configuration
711.
A Actual current value in phase a
A Actual current value in phase b
A Actual current value in phase c
