ASSEMBLY INSTRUCTIONS
1b. For curved back flat panel: Attach two TV brackets
left and right (B)x2 and two TV standoffs, each with
four spacers (*), four washers (OO), and four screw
(*).
*Note: 5 mm spacer (PP) or a 14 mm spacer (QQ) can
be used depending on your TV.
**Note: TV brackets can be attached with M4 x 35 screws
(KK), M6 x 35 screws (LL), M8 x 35 screws (MM),
depending on your TV.
Hardware Used
M4 x 35 Screw
KK
M6 x 35 Screw
LL
MM M8 x 35 Screw
OO M8 Washer
5 mm Spacer
PP
RR TV Standoff
ASSEMBLY INSTRUCTIONS
2. If screws are too long, additional 5 mm spacers (PP),
14 mm spacers (QQ), and a washer (OO) may be
needed.
Hardware Used
QQ M8 Washer
5 mm Spacer
PP
10 mm Spacer
OO
1b
OO
x 4
x 4
x 4
x 4
14 mm Spacer
QQ
x 8
x 2
2
x 4
x 8
x 8
8
RR
x 8
QQ
PP OO
OO
