ASSEMBLY INSTRUCTIONS
Dual Wood Stud Installation
8. Hold the mounting template (C) in the desired position
and use a pencil to mark two hole locations.
Note: Use a bubble level to level the mounting template
(C).
Mounting Template
C
9. Pre-drill 2 holes with a 5/32 in. Wood Drill Bit to a
depth of 2.36 in.
Wood Drill Bit
5/32 in. (4.0 mm)
10. Fix the wall plate (A) to the wall with the M7x55 mm
lag bolt (DD) using the 1/2 in socket wrench
(not included).
Note: Use a bubble level (SS) to level the wall plate (A).
Hardware Used
M7x55 mm lag bolt
DD
SS Bubble level
8
x1
9
2.36 in. (60 mm)
Wood Drill Bit
5/32 in. (4.0 mm)
10
x2
DD
x1
11
C
Depth
A
SS
