Assembly instruction
Car assembling should be done by the adults.
Take care of small parts. To avoid choking hazard, keep children away while
assembling. Children under 36 months are prohibited to use.
Please count all the parts carefully before assembling and dispose the plastic
bag properly. To avoid choking hazard, children are not allowed to play with
the bag.
1. Front wheel assembly
Turn over the car body, aim the center of the front wheel (no bulge plastic part)
to front axle, press the button on the middle of the wheel, then insert and push
the wheel into place.
06
Caster wheels
Front wheel
2. Rear wheel assembly
a. First, check whether the rear axle is in the middle of the car, make sure the
axle length that extend out on both sides are same.
b. Aim the center of the rear wheel (with bulge plastic part) to rear axle and
rear motor, press the button on the middle of the wheel, then insert and push
the wheel into place.
c. Turn over the car body, make sure that the assembled wheel is contacted
with the ground, then assemble the other wheel. (If the other wheel can't be
assembled well, please pull out the rear axle until it can't move, try to
assemble again.)
3.Windshield assembly
Windshield
Motor Rear wheel
I I
Align the hooks of
windshield with the
corresponding
openings on the car
body, insert and push
them into place.
07
