Remove the Doors
IMPORTANT: Keep the refrigerator doors closed
until you are ready to lift them from the cabinet.
1. Unplug refrigerator or disconnect power.
2. Using a Phillips screwdriver, remove the three
screws a廿aching the hinge cover, and then
remove the hinge cover with the entire harnesses
a廿ached
0 Screws
3. Separate the two connectors on the left side
door. To remove the wire connector, press
the top of the connector ( B ) and separate什
from the other one. To remove the water coupler
from the hinge, twist and pull the clips from the
coupler
Remove the water line ( C ) while pressing the
movable part ( D ) of the water line coupler.
＠
4. Remove the 3 screws ( E ) fixed on the hinges, with
a Wrench ( 8mm ) and l ground screws ( F )
a廿ached to the hinge with Ph
Remove the upper left door hinge ( G ) .
@
． ，
三
＠ ＠
ips ( + ) screwdriver
仆
交
5. Use your both hands to open the door more
--
than 90'. Lift it up and take it off.
^-
/
/ /
4
6. If necessary, remove the 2 hex head bolts hinges
( I ) with an Allen wrench ( 5 mm ) .Remove the lower
left door hinge ( H )
0 -
产
f} Allen wr e nch
Replace the Doors
1. If removed, reinstall the bo廿om hinge.
2. Using two or more people, set the refrigerator
door onto the bo廿om hinge
3. Insert the top hinge into the top of the door
4. Using the three screws removed eorlier. fasten
the top hinge to the top of the cabinet
NOTE: Left-hand door only, replace the ground
screw into the top hinge, rea廿ach the wire
harness, reconnect the water line, make sure the
clips are properly connected to the coupler
5. Repeat steps l through 4 to replace the
opposite door.
6. Using the three screws removed earlier, reinstall
the top hinge cover and control panel to the
top of the cabinet
-
－
－
