4.5 Installation
4.5.1 Decalcificator resin washing where it is installed as acces-
sory
First of all fill the distributor's water circuit, it is advisable effect the water
softener resin regeneration (if installed)
operating in the following manner:
– insert the pipe of the bottom faucet in a container suitable for this use
– open the faucet (Fig.4.13)
– insert the key in the door switch (Fig.4.12)
– Let the water flow until it is clear (Fig. 4.14).
– Take out the key and close the faucet.
BVM972 and BVM952 assembles as standard the filter cartridge and does not
provide for the above mentioned procedure application. In this case, just link
DA to the mains and proceed with the hydraulic circuit filling.
4.5.2 Filling of water circuit
INSTALLATION PROCEDURE
The installation procedure is valid only for the single boiler distributors. In
particular, expresso boiler and polisulphone boiler fitted with level probes.
EXPRESSO SINGLE BOILER
At the line output, the distributor will be put in condition of FIRST INSTALLA-
TION. As soon as it reaches the location, the operator will link only water (both
in case of water supply connection and autonomous tank) and the mains.
The distributor will automatically require water until micro lack of water
reaches N.C. for at least 15 seconds. In this condition D.A. switches on the
pump and, with resistance OFF, will supply 200 cc of water (measured through
the fan). Following this procedure the distributor installation date is stored.
Once the date has been confirmed, D.A. waits 10 seconds and soon after it
will start to heat water in the boiler.
POLISULPHONE BOILER with LEVEL PROBES
At the output of BV lines the distributor will be put in condition of FIRST
INSTALLATION. As soon it reaches the location the operator will link only
water (both in case of water supply connection and autonomous tank) and
the mains.
The distributor will automatically require water until the maximum level
probes detect the presence of water. After this procedure the distributor
installation date is stored. Once the date has been confirmed, D.A. waits 10
sec and soon after it will start to heat up water in the boiler.
SINGLE STAINLESS STEEL BOILER FOR SOUPS
At the output of BV lines, the distributor will be put in condition of FIRST
INSTALLATION.
As soon it reaches the location the operator will link only water (both in case
of water supply connection and autonomous tank) and the mains.
The distributor , in condition of OFF resistance, will automatically require
water and will open the electrovalve 2 to vent air which is in the boiler.
This condition will last 200 seconds. At the end of this timeout, the distri-
butor will close the electrovalve 2 and the input water ev for 20 sec. After
this period, the water loading will last until the micro lack of water is N.C.
for a time exceeding 5 sec (this operation is linked to a second timeout of
200 seconds). In this condition D.A. automatically activates the electrovalve
2 which will supply 20 s of water.
At the end of the supply, the micro lack of water returns become N.C. After
this procedure the distributor installation date is stored. When the date
is confirmed, D.A. waits 10 seconds and soon after it will start to heat up
water in boilers.
DOUBLE BOILER
At the output of the lines, the distributor will be put in condition of FIRST
INSTALLATION. As it reaches the location the operator will link only water
(both in the case of linking to the mains and autonomous tanker) and the
mains.
The distributor, in condition of resistances OFF, will automatically require
water and will open the electrovalve 2 to vent the air which is in the stain-
less boiler.
This condition will last 200 seconds. At the end of this timeout, the distributor
will close the electrovalve 2 and the water input ev for 20 sec.
After this time water loading will continue until the micro lack of water is
N.C. for a time exceeding 5 sec (this operation is linked to a second timeout
of 200 seconds). In this condition the D.A. activates the electrovalve 2 and
will supply 20 sec of water.
At the end of the supply, the micro lack shall return to N.C. After 10 sec D.A.
activates the expresso pump, and, on condition of resistance OFF, it will supply
20 cc of water through the coffee ev (measured through the fan).
After this procedure, the distributor installation date is stored. When the
date is confirmed, D.A. waits 10 seconds and soon after it will start to heat
up water in the 2 boilers.
At the end of the water filling, effect a cleaning cycle of the mixer group
so as to fill all the circuits and remove eventual residues from the boiler
(Fig.4.16).
Before connecting the power supply, ensure that the distributor has been
connected to the water mains and that the water tap has been turned on.
4.5.3 Cleaning of the parts in contact with food substances
With distributor switched on effect a cleaning of the mixers pressing the
buttons according to what is described in the service functions so as to eli-
minate any dirt from the coffee boiler and the instant boiler.
– wash your hands carefully
– prepare an anti-bacterial cleaning solution with a chlorine base (products
that can be purchased in pharmacies) carefully following the indications
on the product instruction labels.
– remove all the product containers from the distributor (Fig.4.17)
– remove the lids from the product containers covers and product chutes
(Fig.4.18). Dip all in the solution previously prepared
– remove all the powder chutes, water funnels, mixing bowls and whippers
and silicone tubes and dip these parts also in the prepared solution
(Fig.4.18)
– with a cloth soaked with the solution clean the whipper assembly base
(Fig.4.20)
– the parts must soak in the solution for the time indicated on the solutions'
instruction label.
– Recover all the parts, rinse them abundantly, dry them perfectly and
proceed with the re-assembly in the distributor.
For further safety after the assembly of the parts, effect some auto-
matic cleaning cycles so as to eliminate any eventual residues.
4.5.4 Payment system installation
The distributor is supplied without any payment system:
The installation of the payment system is the responsibility of the installation
technician.
Bianchi Vending Group spa will not take responsibility for any eventual
damage to the machine itself and/or to things and/or persons due to incor-
rect installation.
– open the board and coin mechanism protection door (Fig. 4.21)
– Connect the payment system (Fig.4.22) to the Master board.
The selectors must be directly connected to the Master board the and the serial
executive systems through the interface cable supplied with the machine.
Then go into programming for the correct settings.
Consult chapter" 5.0 SOFTWARE
the parameters, that must be coherent with the system used.
Check the payment system connections, by consulting the diagram of the
sheet shown.
– Hook the coin mechanism (Fig. 4.23).
4.6 Product container loading (with machine off)
4.6.1 Loading containers
– so as to effect the loading is necessary remove each container.
Particularly, for the coffee bean container, it is necessary close the chute
door before removing the container (Fig.4.26).
– remove the covers of each container and load the product according to
the product indicated on the label (Fig.4.27)
– pay attention that they there are no clots, avoid pressing the product
and using an excessive quantity, so as to avoid its aging in relation to the
consumption forseen in the time period between two loadings.
Bvm952
The BVM952 vending machine is equipped with an openable upper case.
This opening gives access to the containers to load the product.
Figures 4.24 and 4.25 show the correct operations to open/close the case.
Caution! Tighten the spring shown in figure 4.25 before closing the
case.
Check the container product capacity in the section TECHNICAL CHARACTE-
RISTICS.
4.6.2 Cup loading
Use only cups suitable for automatic vending machines,
features by consulting the chapter 1.0 "Technical Specifications."), avoid
compressing the cups between
rotate the turret manually.
First filling
In installation phase with the cup dispenser completely empty, operate as
follows:
– Check that the cup column is not aligned with the distribution outlet,
then fill all the columns proceeding in an anti-clockwise sense, opposite
sense (when the column is aligned with the distribution outlet), close
the door and switch on the machine so that the cup column rotates and
automatically places itself in a position in which it is not aligned with the
inlet and then proceed to fill (Fig.4.28)
– Put the cup turret's lid back on and snap in the spring band (Fig. 4.29).
Normal filling
The cup column should normally filled with the machine off, simply by opening
the front door, lifting the lid and inserting the missing cups.
4.6.3 Spoon loading
Attention! Only use appropriate stirers to be used in automatic vending
machines.
– Remove the metal weight from the spoon dispensing column (Fig. 4.30)
– insert the spoons with their pack wrapping in the column and when they
are positioned on the bottom cut and remove the wrapping (Fig. 4.31)
– once the loading is completed put the weight back in the spoon dispensing
column.
– Check that the spoon are cut burr-free, that they are not bent and that
they are all placed horizontally (Fig.4.32).
4.6.4 Insertion of waste grounds bag
– insert the plastic bag wrapping it on the support itself (Fig. 4.33)
– Use plastic bags that are sufficiently long so that they touch the bottom
of the distributor.
- Make sure that the liquid collection tank is in the correct position (Fig.
4.33) and periodically empty it.
