8g -AUTOMATIC RE-CLOSING PROGRAMMING:
Close the door completely.
•
Press once button SET (led DL3 starts flashing slowly).
•
Press once the button BREAK; led DL3 starts flashing quickly indicating that the control panel is about to count the re-closing
•
timing.
To stop the count, press once again the button BREAK (led DL3 will turn off). Maximum re-closing time programmable is 120
•
seconds. If you want to disable this function press once SET and then press BREAK twice (2 times) within 2 seconds.
9 – PROGRAMMABLE FUNCTIONS BY DIP SWITCH SW1 - SW2
SW1 DESCRIPTION WITH DIP ON
1 The control panel ignores the Start function if the gate is
already opening.
2 The control panel works without the encoder (in this case the
anti-crashing system is not activated).
3 Select a resistive safety edge.
4 Output 22 and 23 (24 Vdc) are set to work with an electric
lock.
SW2 DESCRIPTION WITH DIP ON
1 Extra pressure (inversion) of 2 sec. during starting.
10 - TRIMMER DESCRIPTION
Trimmer DESCRIPTION
SENS It adjusts the sensitivity of the door (anti-crashing function) when it moves. If turned unticlockwise (-) sensitivity
very high. If turned clockwise (+) sensitivity very low. This parameter gives the security level of the installation.
POWER Force adjusting. Anticlockwise (-), minimum force; clockwise (+) max force.
PW. RALL Force adjusting during slowing down space. Anticlockwise (-), minimum force; clockwise (+) max force.
11 - SEPARATED BUTTONS FUNCTION
To convert the input START into an input of only CLOSING: cut off power supply, keep pressed buttons SET and BREAK and give power
back at the same time until led DL3 will flash.
To convert the input PED into an input of only OPENING: cut off power supply, keep pressed buttons WORK, SET and BREAK and give
power back at the same time until led DL3 will flash.
12 - RESTORE THE INPUTS AS SEQUENTIAL/STANDARD INPUT (OPEN, STOP, CLOSE, OPEN)
To restore the input START: cut off power supply, keep pressed buttons SET and WORK and give power back at the same time until led
DL3 will flash.
To restore the input PED: cut off power supply, keep pressed buttons BREAK and WORK and give power back at the same time until led
DL3 will flash.
NOTICE: normally the control panel is always delivered with the inputs START and PED as SEQUENTIAL/STANDARD inputs from the
factory.
DESCRIPTION WITH DIP OFF
The control panel accepts start impulse both during opening and
closing.
The control panel requires the encoder to work.
Select a mechanical safety edge working with a switch.
Output 22 and 23 (24 Vdc) are set on courtesy light.
DESCRIPTION WITH DIP OFF
Extra pressure (inversion) of 2 sec. not working.
