Byte 2 (maximum motor current [%])
Bit Description
Bit 0 ... bit 7
maximum current in the
three phases
Byte 3 (thermal model)
Bit Description
Bit 0 ... bit 7
model of thermal load (trips
at 115 %)
Byte 4 (device type)
Bit Description
Bit 0 ... bit 3
device type
Bit 4 ... bit 7
not used
Byte 5 (low byte) and 6 (high byte) as 16-bit data word (maximum current value
[A])
Bit Description
Bit 0 ... bit 7
maximum current that
occurs in the three phases
Bit 0 ... bit 7
Revision 1, dated 01/2021
Value
255 % (maximum) 2.5-fold
in relation to the currently valid nominal current
Value
255 % (maximum) 2.5-fold
in relation to the currently valid nominal current
Value
®
0000: MOTUS
®
0001: MOTUS
Rest: Not used
not used
Value
current value in 10 mA; for example 1267 = 12,67 A
IO-Link 3 A
IO-Link 9 A
