IO-Link
specification
reverse polarity protection
transfer rate
cycle time
process data quantity
IO-Link ports
power consumption
General data
mounting position
mounting type
operating mode
Degree of protection
min. / max. power dissipation
dimensions (W x H x D) CrossBoard
Ambient conditions
pollution degree
ambient temperature (operation)
ambient temperature (storage/transport)
Connection data
connection description
connection method
conductor cross-section, rigid
conductor cross-section, flexible
conductor cross-section [AWG]
stripping length
connection description
connection method
conductor cross-section, rigid
conductor cross-section, flexible
conductor cross-section [AWG]
stripping length
tightening torque
Standards/regulations
standards
Revision 1, dated 01/2021
®
30Compact
60Classic
for DIN rail mounting
V1.1.1
yes
230.4 kbps (COM3)
30 ms
8 bytes (input data)
2 bytes (output data)
1 COMBICON, 3-wire
type 65 mA ± 15 % (24 V DC)
max. 150 mA
vertical (motor outgoing terminal below)
side-by-side, with derating
100% duty cycle
IP20
0,88 W / 4,1 W (3A version)
0,88 W / 7 W (9A version)
22.5 mm / 160 mm / 120 mm
22.5 mm / 160 mm / 156 mm
22.5 mm / 200 mm / 156 mm
22.5 mm / 175 mm / 138 mm
2
-5°C ... 60°C (note derating)
-40°C ... 80°C
Control circuit
push-in terminal
0.2 mm² - 2.5 mm²
0.2 mm² - 2.5 mm²
24 - 14
10 mm
Load circuit
screw type terminal
0.2 mm² - 2.5 mm²
0.2 mm² - 2.5 mm²
24 - 14
8 mm
0.5 Nm – 0.6 Nm / 5 lb -in – 7 lb
f
IEC 60947-1
EN 60947-4-2
IEC 61508
ISO 13849
