Memory - Quality Espresso GAGGIA G6+ Manual De Instrucciones

7.2 TECHNICAL PERSONNEL MENU
7.2.5 – MEMORY
- The V6+ is fitted with a USB port, under the drain tray, which permits plugging in a USB memory stick and
copying the machine's configuration for exporting this to other machines. In the same way, users may
export the screen saver images to a USB memory stick or replace the existing ones with new ones.
- Example: copy the configuration data from a USB memory stick to a V6+ machine.
1. Select the operation to be performed (Fig. 1), in this case, load the data stored on a USB memory stick, which
has been obtained from another machine for copying onto our machine.
2. Press the advance button to confirm the operation (Fig. 2).
3. When finished, a screen will appear to verify that the selected operation has been performed successfully, Fig.
4. Otherwise, the selected operation will appear with an "X" to indicate that the operation has failed, Fig. 5.
SELECT
Figure 1.
Figure 4.
Figure 5.
CONFIRM
Figure 2.
- Operation finalised
-
successfully
-
- Operation failed.
-
43
CONFIGURATION
SCREEN SAVER IMAGES
PASS DATA FROM USB TO V6+
PASS DATA FROM V6+ TO USB
Verify
100%
Figure 3.
USB NOT DETECTED
i - - If we try to perform any
of the described
operations and the USB
memory stick is not
detected, the above
screen will appear.
NEXT SCREEN
