Product Features - Foodsaver Ms2000 Owner's Manual

Product Features

4 3
Upper Foam Gasket
Lower Foam Gasket
Extra-wide Sealing Strip
Removable Drip Tray
5 US: www.FoodSaver.com | CA: www.FoodSaver.ca | MX: www.oster.com.mx/foodsaver
MS2000_24EFSM1.indd 5-6 MS2000_24EFSM1.indd 5-6
Place Handheld in dock Cordless Handheld being
with FoodSaver logo and removed from the dock
battery light facing up
Handheld
Latch (Open)
5
Handheld Latch
Easy Lock Latch:
Operate
Adjust Back
to Operate
Store
Adjust Center
to Store
Open
Adjust Forward
to Open
Seal Profile
Vacuum Mode
Marinate Mode
Removeable Reservoir
2 1
The user-friendly, intuitive control panel makes it easy for
you to get the most out of your FoodSaver
Seal Indicator Light
1
This light has two uses:
1. Pulsing light indicates Sealing process is engaged.
2. Flashes to indicate error.
Vacuum Indicator Light
2
This light has two uses:
1. Pulsing Light shows Vacuum and Seal process is engaged.
2. Flashes to indicate error.
Seal Button
3
This button has three uses:
1. Press to create a seal when making bags from a FoodSaver
2. Press to immediately stop the vacuum process and begin sealing the bag. This prevents crushing
delicate items such as bread, cookies and pastries.
3. Press to create a seal on multilayer film bags (such as a potato chip bag) to keep food sealed
airtight.
Vacuum + Seal Button
4
This button has two uses:
1. Press to vacuum seal food airtight. Appliance shuts off automatically.
2. Press to pause vacuum process at any point.
Handheld
5
This handheld has 3 uses:
1. Leave Handheld docked in the appliance to vacuum + seal.
2. Remove Handheld from appliance and vacuum FoodSaver zipper bags, reusable bags, containers,
jar sealer, and bottle stopper. If fully charged, the handheld can vacuum up to 35 quart zipper
bags and run 4 marinate cycles on the 10-cup container. Hold handheld upright throughout the
entire handheld cycle when using the reservoir with the zipper bags and reusable bags to ensure
contact with the valve.
3. Remove Handheld from appliance and use the marinate function with the FoodSaver Preserve and
Marinate containers. Hold handheld upright applying downward pressure throughout the entire
vacuum cycle when using the reservoir.
GREEN = the appliance is ON and ready to vacuum seal
PULSING GREEN LIGHT = the appliance is working
OFF = the vacuum sealing cycle is complete
*The light will turn back to GREEN when it is ready for a new vacuum sealing cycle
Consumer Service: US: 1-877-777-8042 CA: 1-877-804-5383 MX: +52 55 5366 0800
System:
®
Roll.
®
6
