TECHNICAL DATA / DECLARATION CE
Type / reference
Input voltage
Nominal input current
Nominal / Max pressure
Maintenance-free battery
Sound pressure level LpA
Sound power level LwA
Length x width x height (mm)
Gross weight / Net weight
Charger input voltage
Charger output voltage
Nominal charge current
Insulation class

DECLARATION OF CONFORMITY CE

The company POGGIO-SOLUTIONS declares that the product mentioned below:
Battery-powered compressor R180 (ref 900180) and its charger
Complies with the following directives:
2006/42/EC, 2014/30/EU, 2014/35/EU, 2000/14/EC amanded by 2005/88/EC, IEC61056-1, 2014/35/EU,
2011/65-EU & 2015/863 annexe 2
et évalué selon les normes applicables en vigueur suivantes :
EN 1012-1:2020 -EN 60204-1:2018, EN 55014/2017 - EN 55014-2:2015, EN60335-1: 2012+AC:2014+All:
2014+Al3:2017+Al:2019+Al4:2019+A2: 2019 - EN 62233: 2008+AC: 2008, EN61056-1:2012, EN 60335-2-
29: 2004 + A2: 2010 + All:2018 à to be used in conjunction with EN 60335-1: 2012 + All:2014 + AB:2017 +
Al:2019 + Al:2019 + A14:2019 and EN 62233: 2008, EC/1907/2006
Procedure for compliance with Directive 2000/14 / EC,
modified by 2005/88 / EC
Réf
References of the notified body:
R180 Intertek Testing Services Shanghai
900180 Building No .86, 1198 Qinzhou Road (North), Shanghai 200233, China
Technical files available
with Mr . Martin PABOIS
Power level
measured acoustics
LWAm :
93 dB(A)
LE CANNET, 15/07/2020
Alain PROSPER - Company manager
POGGIO-SOLUTIONS
854, avenue du campon
06110 LE CANNET - FRANCE
R180 - ref. 900180
12 V DC
11 A
10 / 20 BAR (150 / 300 PSI)
Type AGM - 12 V - 7 A .h
75 dB(A)
95 dB(A)
275 x 250 x 100 mm
6,0 kg / 5,5 kg
100-240 V 50/60 Hz
14,7 V DC
800 mA
II
Power level
guaranteed acoustics
LWAg :
95 dB(A)
EN
Numbers
lots
1002000
à 2212999
27
