EN OPERATING INSTRUCTIONS
1. PRESENTATION OF THE R180
• The R180 is a powerful professional air compressor
for inflating wheels and bicycle accessories . It is
autonomous because it operates on a 12 V battery . It
provides rapid and precise inflation .
• It is intended for amateurs or professionals in the world
of cycling, and more generally for all users who need a
nomadic high pressure compressed air source .
• It can provide real and continuous pressure up to 20 bar
(300 PSI)
• Its oversized 12 V motor operates on a 7 .0 A .h . It can
also work directly on a 12 V cigarette lighter socket . This
capacity gives it great autonomy (several tens of wheels
can be inflated without recharging *)
• Pressure can be programmed and stored from 0 .35 to
20 .3 bar (5 .0 to 295 PSI)
• 3 display units are possible: BAR / PSI / kPA . The
conversion is done automatically .
• The appliance
programmed pressure is reached
• The pressure obtained is very precise
• This compressor is of the "oil-free" type . it requires no
maintenance
• Charging is done either using the 100-240 V AC / 12 V
DC charger or by the 12 V DC cigarette lighter socket
16
of a motor vehicle
• It is fitted with a reinforced professional type HP hose
to which all types of fittings can be screwed (type M11
thread) . A reversible screwdriver bit for «presta» and
«schrader» type valves is supplied with the device
• The R180 is clever, it has a retractable steel bike mount .
Practical, it can support bikes up to 9 kg (subject to
stable surface)
• The R180 is easy to transport and store thanks to its
carrying case with interior pockets

2. POSSIBLE USES:

• ROAD BIKE:
- tire inflation
- inflation of tubulars
- tubeless inflation **
• MTB / GRAVEL :
- tire inflation
- tubeless inflation **
- inflation of shock absorbers and forks
24
stops automatically when
* Depends on the type and section of the tire, on the desired pressure
• AUTOS, MOTORCYCLES and other VEHICLES
- tire inflation (subject to control by CE measuring
device)
• Inflatable GAMES / TOYS
- buoys and mattresses
- balloons

3. CHARGE THE BATTERY

IMPORTANT: CHARGING CAN ONLY TAKE PLACE WHEN
THE MAIN SWITCH IS "ON".
The battery can be recharged in 2 different ways :
a) CHARGE THE BATTERY ON THE 100-240 V DC MAINS
• The R180 can be recharged using the 100-240 V AC /
12 V DC charger supplied
corresponding to the country model . You can use the
adapter for use in the UK .
the
17
• Connect the plug
to the 100-240 V socket (fig . B1) .
16
• Turn the main switch
up to indicate that the charger is working . The green
LED also lights up (fig . A2) . If the battery is less than
31
50% charged, the orange LED
• When the battery is fully charged, the green LED
on and the charge indicator
can then unplug the charger and replace it in the slot
provided for this purpose .
NOTE: the compressor can be used while the charger
is connected, provided that the battery is charged
16
to more than 50% (green led on) . This type of use is not
recommended when the battery is less than 50% charged .
b) CHARGE THE BATTERY USING THE 12 V DC
CIGARETTE LIGHTER SOCKET.
• The R180 can be recharged using the cigarette lighter
socket (fig . C1)
20
• The main switch
• Insert the plug
15
• Plug the plug
20
of your vehicle and set the genral switch
C3)
• Turn the main switch
. Choose the type of plug
16
to the socket and the charger
15 3
to ON . The red LED
2
lights up (fig B2)
32
displays 4 segments . You
23
must be in the OFF position
2
into the socket (fig C2)
into the female cigarette lighter socket
2
to ON . The orange LED
2
**According to types and models
lights
33
is
33
9
to ON (fig .
