28
Power
supply:
Data transfer
parameters:
Data
interface:
Data
format:
Connections Back panel of the
Gas exhaust pipe:
Front panel (to be connected to the front panel of ViscoPump III modules)
Pneumatic connectors: Pressure/suction venting, to be connected to viscometer.
Overflow guard for VZ 8552 suction line:
Type VZ 8561 ViscoPump III for optoelectronic sampling
Measurements stand AVS
Type VZ 8562 ViscoPump III for TC sampling
TC viscometer:
Operating indicator: Green LED (voltage indicator)
Various add-on devices:
Casing:
Dimensions:
Weight:
Front panel:
Ambient conditions:
Climate:
Pollution degree:
®
via AVS
measuring systems AVS
Input:
+24 Volt DC, 800 mA
Power Input: 19 W
bidirectional, serial interface according to EIA RS-232-C
word length 7 bits, 2 stop bits, 4800 baud, no parity
device:
96-channel VG bar for contact making with the module plugged in a controller unit,
including voltage supply and 2 serial interfaces
Stainless-steel tube used to expel or suck the gases delivered by the rotary pump
Capacitive sensor: Round-plug connector, 4-channel,
Screwed cap according to DIN 45321
®
/S:
Round-plug connector with bayonet catch,
DIN 5 channels for AVS
4-channel DIN socket
EIA-RS-232-C interface with 9-channel Submin D plug
No casing, module in plug-in design
approx. 50 x 173 x 140 mm (W x H x D) overall dimensions
approx. 0.8 kg
2 mm anodized aluminum
Do not use the device in hazardous locations!
Ambient temperature: + 10 ... + 40 °C for operation and storage
Humidity according to EN 61 010, Part 1:
Max. relative humidity 80 % for temperatures up to 31 °C,
linear decrease down to 50 % relative humidity at a temperature of 40 °C
Pollution degree IP 20, indoor use only.
®
®
370, AVS
®
/S (measurement stand), 5-channel DIN socket
®
470 und AVS
Pro
