NOTE!
Disposing of tubes and containers
Comply with national disposal and hygiene rules when disposing of tubes, collec-
ted fluid, and the containers.
5.7

Tube Overview

Three different tube sets are necessary to operate the system. The following table
lists each type of tube set and its application.
Article number Description
Tube set for irrigation, single-use,
AQL-110
for Aquilex® Fluid Control System
Tube set for suction, single-use,
AQL-111
for Aquilex® Fluid Control System
Aquilex® Fluid Control System complete tube set (inflow and
AQL-112
outflow), disposable, sterilized using ethylene oxide
Tube set for vacuum incl. filter, 30-day use,
AQL-114
for Aquilex® Fluid Control System
Table 1: Tube sets
5.8

Connecting the Outflow Tube Set

WARNING!
Combination of low set pressures and excessive vacuum pressures
When using the Aquilex® Fluid Control System with tissue removal systems, e.g.
MyoSure®, the combination of low set pressures and excessive vacuum pressures
may result in a significant loss of intrauterine distension pressure which has the
potential to affect the visibility of the surgical field. Conversely, when employing a
high distension pressure, the deactivation of the tissue removal system can lead to
pressure peaks that can exceed 150 mmHg.
