Adapting the humidifier
Locking catch

3.3 Breathing mask

Fitting the mask
1. Adjust the forehead support of the mask (if present).
2. Connect the headgear to the mask.
3. Position the mask.
4. Adjust the headgear so that the bulge of the mask only results in low pressure
to prevent pressure points on the face.
Note
For further instructions, please refer to the operating instructions for the rel-
evant mask.
Warning!
Full-face masks must be equipped with an emergency exhalation valve so
that you can breathe through nose or mouth in the event of any device fail-
ure. Full-face masks without an emergency exhalation valve may not be
used!
1. If necessary, release the corrugated tubing from
the therapy unit.
2. Click the humidifier into position from the front
onto the sleep apnea unit. The inlet connection
and the heating rod must be directed towards to
the sleep apnea unit. Take care to engage the
lock.
3. Connect the corrugated tube to the outlet con-
nections of the humidifier.
4. To release the humidifier, press the locking catch
and withdraw it off the unit.
Set up of equipment
