No. Description
SOLO pad
13
Press to switch to SOLO mode .
POWER SWITCH
14
Provides power to the pump .
FOOT PEDAL connection
15
Connection port for 5-Way Foot Pedal .
RUN/STOP PAD
16
Starts and stops the pump
REMOTE HAND CONTROL connection
17
Connection port for the remote hand control .
HANDPIECE interface connection
18 Connection port for handpiece or FMS CONNECT Interface Cable (Contact your DePuy
Synthes representative for availability) .
Fill Chamber pad
19
Press to fill the Fill Chamber .
Fill Chamber bracket
20
Supports Fill Chamber .
PRESSURE SENSOR QUICK CONNECT port
21
Connects/disconnects the pressure sensor to the pump .
IRRIGATION Auto-locking slot
22
Locks the tubing in place around the IRRIGATION roller pump .
LOW PRESSURE Alarm
23
Indicates low joint pressure .
HIGH PRESSURE Alarm
24
Indicates high joint pressure .
BLOODSTOP™ Indicator
25
When illuminated, indicates pump is in BLOODSTOP mode .
