5. Fan Assembly. (cont.)
With the hanging bracket secured to the outlet
safety cable loop
wood
box and able to support the fan, you are now
ceiling
ready to hang your fan. Grab the fan firmly with
joist
two hands. Slide downrod through opening in
wood screw
hanging bracket and let hanging ball rest on
and washer
the hanging bracket. Turn the hanging ball slot
until it lines up with the hanging bracket tab.
safety cable
WARNING: Failure to align slot in hanging
ball with tab in hanging bracket may result in
hanging bracket tab
serious injury or death.
CAUTION: Due to the size (circumference) hanging ball slot
of this fan, it is advisable to seek the help of
another person to hold the stepladder in place
and to then help lift the fan up to you once you
are set on the ladder.
motor assembly
Find a secure attachment point (wood ceiling
joist highly recommended) and secure safety
cable. It will be necessary to use a heavy duty
wood screw, washer and lock washer (not
supplied) with the safety cable loop. If
necessary, adjust the loop at the end of the
safety cable. The loop at the end of the safety
cable should just fit over the threads on the
wood screw. Test safety cable by pulling on loose
end of cable with pliers. If the safety cable slips,
the loop must be adjusted tighter. Extra cable
slack can be left in ceiling area.
