Selection of battery charger
! ATTENTION: where machines are shipped without
batteries, the machine and the battery charger are
factory set for GEL-AGM batteries as the default
type of battery, the battery charger setting MUST
be changed as described below. Failure to observe
these instructions could result in damage to the
battery. Depending on the type of battery selected
(wet lead-acid or sealed gel / AGM), the battery
parameters of the machine MUST be adjusted if
the section "Batteries".
DIPSWITCHES: SW1
DP1 DP2
ON OFF
OFF OFF
OFF ON
ON ON
DIPSWITCHES: SW2
DP1 CHARGING
CURRENT
ON 15A
OFF 25A DEFAULT SETTING
SW1
DP1 DP2
OFF OFF
ON ON
Fitting the squeegee
! ATTENTION: before carrying out the operations
- Connect the suction hose to the squeegee,
bending it to the position as illustrated.
- Loosen the two knobs.
- Locate the two threaded pins in the slots on the
support.
- Tighten the two knobs.
The position of the squeegee is factory-set. Should the
squeegee blade require adjustment, refer to the section
"Squeegee adjustment".
CHARGING CURVE
IUIa-ACD for Gener-
ic Wet batteries
IUIa-GEL for DEFAULT SETTING
Exide-Sonnenschein
Gel batteries
IUOU-GEL for Gel
and AGM batteries
IUIa-AGM for Dis-
cover AGM batteries
DP2 TCL
FUNCTION
ON TCL DEFAULT
DISABLED SETTING
OFF TCL
ENABLED
SW2
DP1 DP2
OFF OFF
ON ON
ON
Squeegee adjustment
! ATTENTION: before carrying out the operations
drying. With time, and the constant wiping action, the edge
a new blade is required. The state of wear should be
checked frequently.
To ensure faultless drying, the squeegee must be adjusted
as illustrated, in such a way that the edge of the rear blade
at all points along its length. The angle of the blade during
operation can be adjusted by regulating the height of the
two wheels positioned in front of/behind the squeegee.
