System Example - Uponor Smatrix Wave Guía Rápida

UK
Contents
CZ
DE
Uponor Smatrix Wave components ..............................4

System example ................................................................4

DK
Safety instructions .......................................................5
Controller ..........................................................................5
Thermostat/System device ...............................................5
EE
Thermostatic Head ............................................................5
Quick Guide ...................................................................7
ES Installation ........................................................................7
Register thermostat and/or system device to a
controller...........................................................................9
Register thermostatic heads to controller in rooms
FI
with a thermostat ............................................................10
Register thermostatic heads to controller in rooms
without a thermostat ......................................................11
FR
Unregister one channel or system device ........................12
Unregister all channels ....................................................12
Room bypass ...................................................................12
Other functions ...............................................................12
HR
Technical data .............................................................13
HU
IT
LT
LV
NL
N O T E !
This is a quick start guide to serve as a
reminder for experienced installers. We
NO
strongly recommend reading the full manual
before installing the control system. See QR-
code for download link.
PL
PT
RO
RU
https://www.uponor.co.uk/smatrix/downloads.aspx
SE
SI
SK
4
QUICK GUIDE
Uponor Smatrix
Uponor Smatrix
Wave
Wave Uponor Smatrix
U K I N S TA L L AT I O N A N D O P E R AT I O N
Wave
M A N U A L
U K I N S TA L L AT I O N A N D O P E R AT I O N
M A N U A L
U K I N S TA L L AT I O N A N D O P E R AT I O N
M A N U A L
Uponor Smatrix Wave
components
An Uponor Smatrix Wave system may be a combination
of the following components:
Uponor Smatrix Wave X-165 (controller)
Uponor Smatrix A-1XX (transformer A-1XX)
Uponor Smatrix Wave A-165
(antenna A-165)
Uponor Smatrix Wave I-167 (interface)
Uponor Smatrix Wave T-169
(digital thermostat T-169)
Uponor Smatrix Wave T-168
(digital thermostat T-168)
Uponor Smatrix Wave T-166
(digital thermostat T-166)
Uponor Smatrix Wave T-165
(standard thermostat T-165)
Uponor Smatrix Wave T-163
(public thermostat T-163)
Uponor Smatrix Wave T-162
(thermostatic head T-162)
Uponor Smatrix Wave T-161
(sensor thermostat T-161)
Uponor Smatrix Wave M-161
(relay module M-161)
Uponor Smatrix Wave M-160
(slave module M-160)
System example
1 2 3
1 2
U P O N O R S M AT R I X WAV E · Q U I C K G U I D E
4
3 4
