• Cell phones, televisions, and other devices using
radio frequency energy may cause interference.
This interference may cause EXOGEN to operate
improperly or stop operating completely. While
EXOGEN complies with the limits for Class B
digital devices pursuant to Part 15 of the FCC
rules, it has not been studied with all brands
and models of phone
• The safety and effectiveness of EXOGEN when
used for more than one daily 20-minute treatment
period has not been studied. Patients in the clinical
studies were instructed to apply EXOGEN for one
treatment period of twenty-minutes each day
- The age ranges of the patients in the PMA non-
union studies were 17-86. The effect of EXOGEN
therapy on patients outside this age range has
not been studied
- The age ranges of the patients in the PMA
fresh fracture studies were 17-67. The effect of
EXOGEN therapy on patients outside this age
range has not been studied
• The safety and effectiveness of the use of
EXOGEN has been demonstrated for patients
followed up over a period of 6.5 years (78 months)
• When choosing a treatment site ensure that the
site selected allows for full contact of the trans-
ducer face with the skin. Failure to do so may re-
sult in the transducer being only partially coupled
to the skin. This may reduce the effectiveness of
EXOGEN in treating the fracture.
• Placement of the transducer directly over internal
fixation may result in the treatment signal being
partially or fully blocked and may reduce the
effectiveness of EXOGEN in treating the fracture.
• When choosing a treatment site, the transducer
shall be positioned such that the ultrasound beam
is not impeded by any internal fixation which is
directly in line with the fracture site (e.g., not
directly over metal plating). This may require
placement of the transducer on the opposite side
of the limb or perpendicular to the fracture line.
Correct placement should be confirmed using
radiographic and/or anatomical markers by a
healthcare provider during the fitting of the device.
The site of application should be marked onto the
patient's skin with an indelible marker to guide
repeatable placement.

Display Symbols and Descriptions

Symbol Name
Charging Symbol
Battery Status
Calendar X-Mark
Calendar Checkmark
Calendar Double
Checkmark*
Calendar Double
Checkmark Plus*
Treatment Day
Missed Treatment Day
Countdown Timer
Treatment Day Streak
Treatment Complete
*EXOGEN should be used for only 20 minutes per day, or as prescribed by your doctor.
Description
Flashes to show EXOGEN is
plugged in and charging.
Shows how much charge is left in
the battery.
A 20-minute treatment was not
completed on this calendar day.
A 20-minute treatment was
completed on this calendar day.
Two-20 minute treatments were
completed on this calendar day.
Three or more 20-minute
treatments were completed
on this calendar day.
Day in which at least one full
treatment was delivered
Day in which zero full treatments
were delivered
Counts down from 20 minutes to
show treatment time remaining.
Consecutive treatment days in
which at least one full treatment
was delivered.
Automatically displays when count-
down timer reaches zero to show
that treatment is complete.
