EXOGEN Device (EXOGEN)

EXOGEN (Figure 2) features a transducer at the
end of a coiled cord, color screen, power button
and USB charging port. The cord and transducer
are not removable from EXOGEN.
EXOGEN contains the internal electronics and
battery. It checks the ultrasound signal to make
sure EXOGEN works properly. The transducer
sends low-intensity pulsed ultrasound to the
fracture site through the gel. EXOGEN can also
sense if gel is present on the transducer surface.
EXOGEN stores and displays a calendar of daily
use. This data is available to you and your
physician.
EXOGEN has a mini-USB charging port to allow
you to recharge the battery. EXOGEN will not
communicate with any other electrical devices.
USB charging
port
Coiled cord
Figure 2 – EXOGEN Device

Charger (power supply)

EXOGEN is powered by a rechargeable battery.
A charger (Figure 3) is included with EXOGEN.
Only use this supplied charger with EXOGEN. Do
not plug other chargers into EXOGEN. Other
chargers may cause injury to you or others near
EXOGEN as well as damage to the charger. The
use of chargers, transducers or cables, other than
those supplied, may result in increased radio
frequency emissions or decreased electromag-
netic immunity of the EXOGEN which may cause
EXOGEN to stop working.
The USB plug end of the cord plugs into
EXOGEN. The other end plugs into a wall
outlet. The charger requires a standard US
120 VAC, 60 Hz, household electrical outlet.
Read more about how to charge EXOGEN in
"Getting Started" on page 5.
Color Screen
Transducer
Figure 3 – EXOGEN Charger
Mini USB plug

Strap

The strap (Figure 4) is used to position the
transducer over your treatment site. The strap
has a port in it to hold the transducer in place.
The cap holds the transducer down on the
treatment site. The strap is adjustable to fit
most fracture locations. If your strap does not
fit the location of your fracture, please contact
Customer Service at 1-800-836-4080 to find out
if there is another strap which may fit better.
Button
Figure 4 – EXOGEN Strap
Port
Cap
Strap
