ASSEMBLY
STEP 8 - ADJUSTING THE STEEL CABLE ON THE TOWER
20
NAME
Cable Tensioner
21
NAME
Low profile hex nut
M8
E
NAME
Steel cable
Q
NAME
Load multiplier
R
NAME
Steel cable
THE CORRECT MOUNTING POSITION
OF THE CABLE TENSIONER (20) IS
INDICATED BY THE TRIM LOCATED AT
ITS END! (TRIM FACING UP).
Qty
1x
Qty
1x
Trim
21
20
Figure 8-1
Q
21
20
Q
Figure 8-3
E
R
Figure 8-5
N
25
Figure 8-2
11
Figure 8-4
R
Q
Figure 8-6
X cm
Same distance from
the cables on the
tensioner and the load
multiplier, the
cables should be put
in at the same time
X cm
R
11
