Technical Data; Electric Diagram - Master Bf 35 Manual De Instrucciones

MODEL
Single phase power supply
Air flow
Cosumption
Fuel
Maximal thermal power
Fan electric power
Flue diameter
Fan starting temperature
Safety limit temperature
Fuel tank
Dimensions L x P x H
Net weight (without burner)
Riello Burner

TECHNICAL DATA

BF 35 BF 45
1.900 m³/h 2.800 m³/h
2,84 kg/h 3,95 kg/h
33,7 kW 46,8 kW
245 W 245 W
120 mm 120 mm
55 litres 55 litres
460x1050x1600 460x1050x1600
mm mm
132 kg 137 kg
REG 3 REG 5

ELECTRIC DIAGRAM

BF 75
230V ∼ 50 Hz
4.500 m³/h 5.300 m³/h
6,0 kg/h
Oil
71,1 kW
590 W
150 mm
+35 °C
+100 °C
75 litres
540x1120x1700 680x1220x1885
mm
173 kg
R40 G10S
LF Tension signal
LL LIMIT intervention signal
LB Burner block signal
C Heating / stop / fan commutator
TA Room thermostat
LM LIMIT thermostat
FA FAN thermostat
MB Burner terminal board
B Burner
MGV Fan group terminal board
GV Fan group
P External plug
IMT* Magneto-thermal interruptor qitt
* Outside the machine, under installer's
responsibility.
BF 95 BF 105
6.300 m³/h
7,84 kg/h 8,82 kg/h
93,0 kW 104,6 kW
736 kW 736 kW
180 mm 200 mm
105 litres 135 litres
760x1400x2000
mm mm
197 kg 264 kg
R40 G10S R40 G10S
