PARTS LIST – MAIN UNIT
Item Part # Qty Description
1 B189503GS 1 CRADLE
2 70642GS 2 MOUNT,Vibration, 45°
3 76222GS 4 PPHMS, M8 - 1.25 x 40 mm
4 66365GGS 1 HOUSING, Engine Adapter
5 187746GS 1 ASSEMBLY, Rotor (Inclds Item 7)
6 187745GS 1 ASSEMBLY, Stator
7 65791GS 1 BEARING
8 96796GS 1 WASHER, M8 Flat
9 189949GS 1 DECAL, Cover, Air Cleaner
10 86307GS 4 SCREW, 5/16-24 x 3/4 SEMS
11 99383GS 1 SCREW, 5/16-24 x 7-3/8
12 67022GS 1 GROMMET, Rubber
13 189127GS 1 GROMMET, Rubber
14 189009GS 1 BRACKET, Muffler
15 188551GS 1 GASKET, Exhaust
16 66476GS 2 SCREW, M6-1 x 12 w/Lock
17 189008GS 1 MUFFLER
18 60706GS 2 SCREW, 5/16 - 18 x 3/4"
19 83083GS 1 SCREEN, Spark Arrest
20 81917GS 1 PIN, 4mm x 10 Roll
21 67989GS 10 NUT, Flange Serrated
22 20566GS 1 DECAL, 1-800 #
23 86292GS 1 SCREW, #10 Self Drilling
24 J96068GS 1 SHIELD, Heat
25 SRV66825DGS 1 CARRIER, Rear Bearing
26 74908GS 5 TAPTITE, M5-0.8 x 10
27 86308AGS 4 BOLT, M6-1 x 145mm Stator
28 84409GS 1 SLEEVING, Flexo, HW 1/2" x 15"
29 22695GS 1 FASTEN, On Tab Housing 6P
30 84242GS 1 GROMMET, Plastic
31 77816GS 1 DECAL, Hot Muffler
32 91825GS 1 ASSEMBLY, Brush Holder
33 66849GS 2 TAPTITE, M5-0.8 x 16
34 B4871GS 1 COVER, Bearing Carrier
35 23762GS 2 WASHER, #10 Ext. Shakeproof
5500 Watt Heavy Duty Generator
Washer
Item Part # Qty Description
36 86494GS
37 B2153GS
38 56893GS
39 189948GS
40 77395GS
41 80270GS
42 78299GS
43 83465GS
44 78831BGS
45 B4363GS
46 22097GS
47 22127GS
48 14353621GS
49 26850GS
50 B4986GS
51 92982GS
52 189235GS
53 85652GS
54 92665GS
55 187330GS
56 85000GS
57 B1998GS
58 189157GS
59 189164GS
60 J92039GS
61 189828GS
62 BB3061GS
63 43438GS
64 189521AGS
65 188826GS
66 189949GS
67 73054GS
68 190018GS
900 NSP
17
1 SCREW, M6-1.0 x 16 Wing
2 SCREW, #10 Self Drilling
5 SCREW, 10-24 x 1/2 Crimptite
2 DECAL, Heat Shield
4 NUT, M6 Flange Lock
1 VALVE,Tank
1 BUSHING, Plastic Tank
4 GROMMET,Tank
4 HHCS, M6 - 1.0 x 60, SEMS
1 CAP, Fuel Gauge
4 WASHER, Lock
4 NUT, 1/4-20
1 WIRE, Ground
2 WASHER, M6 Shakeproof
1 DECAL, Ground, Green
1 DECAL, Danger
1 DECAL, Start Instructions
2 MOUNT,Vibration
1 INSULATION, 2 - 1/4"
1 HOOD, Rocker Arm Cover
1 CLIP, Insulation
1 ASSY.,Tank, Fuel 7-Gallon
(Includes Items 41 & 42)
1 ASSEMBLY, Control Panel
4 NUT, Palnut, 3/16"
1 SHIELD, Heat
1 MANUAL, Owners
1 BOTTLE, Oil, 28 oz
1 PLUG, 250V, 30A
1 WIRE, Ground, Panel
1 MANUAL, Engine
1 DECAL, Panel, Control
1 DECAL, Fuel Shut-off
1 PLATE, Stiffener
1 ENGINE
