1.8 Cabling

Connect to the Switch/Hub
•
Plug in one end of the RJ45 network cable to the Switch/Hub port
•
Plug in the other end of the RJ45 network cable to the Wireless Access
Point
Check the installation
The LEDs of the Access Point are clearly visible and the status of the network link can
be seen instantly:
•
With the power source on, once the device is connected, the Power, LAN
and WLAN port LEDs will light up indicating a normal status.
•
If the LAN Port's Link indicator does not light up then check the RJ-45
cable if it is firmly feed to the RJ45 port, while the LAN is link up to the
Switch/Hub, the LAN port's LED will light up.

1.9 Before Configuration

The Wireless MIMO Multi-Function Access Point has a Web GUI interface for the
configuration. The AP can be configured through the Web Browser. A network
manager can manage, control and monitor the AP from the local LAN. This section
indicates how to configure the AP to enable its functions.
This section describes the configuration required by LAN-attached PCs that
communicate with the Wireless MIMO Multi-Function Access Point, either to configure
the device or for network access. These PCs must have an Ethernet interface (or
wireless adapter) installed properly, be connected to the Wireless MIMO Multi-Function
Access Point either directly or through an external repeater hub or by wireless, and
have TCP/IP installed and configured with a fixed IP address that must be in the same
subnet of the Wireless MIMO Multi-Function Access Point. The default IP address of
the Wireless MIMO Multi-Function Access Point is 192.168.1.254 and subnet mask is
255.255.255.0.
Please follow the steps below for PC's network environment installation. First of all,
please check your PC's network components. The TCP/IP protocol stack and Ethernet
network adapter must be installed. If not, please refer to MS Windows related manuals.
