Before Configuration - Atlantis Land NetFly A02-AP1-W54 Guia De Inicio Rapido

product provides a very easy and user-friendly interface for
configuration.

Before Configuration

This section describes the configuration required by LAN-
attached PCs that communicate with the Wireless Multi-
Function Access Point, either to configure the device or for
network access. These PCs must have an Ethernet interface
(or wireless adapter) installed properly, be connected to the
Wireless Multi-Function Access Point either directly or
through an external repeater hub or by wireless, and have
TCP/IP installed and configured with a fixed IP address that
must be in the same subnet of the Wireless Multi-Function
Access Point. The default IP address of the Wireless Multi-
Function Access Point is 192.168.1.1 and subnet mask is
255.255.255.0. For example, when the default network
address of the default IP address of the AP is 192.168.1.1,
then the manager PC should be set at 192.168.1.x (where x
is a number between 2 and 254), and the default subnet
mask is 255.255.255.0.
Please follow the steps below for PC's network environment
installation. First of all, please check your PC's network
components. The TCP/IP protocol stack and Ethernet
network adapter must be installed. If not, please refer to MS
Windows related manuals.
Before you configure this Wireless Multi-Function Access
Point, you need to know the following default settings:
•
Username:admin
•
Password:admin
•
IP LAN address: (192.168.1.1), Subnet Mask
(255.255.255.0)
•
DHCP Server: disable
•
SSSID= default, Channel=6, WEP/WAP=disable
ENGLISH
20
