Communication Slot

All UPS come with an expansion slot for optional communication boards so that the unit is compatible with the
main communication standards.
Some examples:
• Serial port duplexer
• Ethernet network agent with TCP/IP, HTTP and SNMP protocols
• RS232 + RS485 port with JBUS / MODBUS protocol
For more details on the options available, visit the manufacturer's web site.
S
OFTWARE
The CD-Rom provided includes two software programmes that allow the user to perform UPS monitoring,
control and configuration operations.

Monitoring and control software

The Powershield 2 software ensures efficient and intuitive UPS management, by displaying all the most
important information such as input voltage, applied load, battery capacity, etc.
It can also automatically execute programmed shutdown/start-up operations, shutdown of the O.S., sending of e-
mails, sms and network messages when specific user-selected events occur.
Installation Operations:
• Connect the UPS RS232 communication port to a COM port on the PC using the serial cable provided.
• Insert the CD-Rom and select the operating system required.
• Follow the installation instructions. .
• For more detailed information on the installation and use of the software, refer to the software manual in the
Manuals folder on the CD-Rom provided.
Visit the manufacturer's web site to check whether a more recent version of the software is available.

Configuration Software

UPSTools software allows the user to configure the UPS and provides a full view of the system parameters and
status through the RS232 serial port.
Refer to the paragraph UPS Configuration for a list of the possible configurations available.
Installation Operations:
• Connect the UPS RS232 communication port to the COM port on the PC using the serial cable provided.
• Follow the installation instructions given in the software manual in the UPSTools folder on the CD-Rom
provided.
Visit the manufacturer's web site to check whether a more recent version of the software is available.
I
NSTALLATION AND
U
SE
