Charging

b) Slide the bar onto the outlet of the front fork. The tube must be pushed in as far
as it will go. The handlebar height adjustment spikes will point towards the rider.
c) Align the front wheel and the handlebar so that they are on axis as shown.
d) Firmly tighten the two Allen bolts of the "attaching clamp No. 3 in the main il -
lustration" using the Allen key provided.
e) Set the correct handlebar height using the "locking clamp No. 3 in the main
illustration". The height of the handlebar is adjusted according to the size of the
rider, so that he/she can control the electric scooter in the best possible way.
f) Check that the bar is correctly assembled and adjusted.
5. Charging
The charging is performed with the supplied charging adapter. First of all, uncover
the rubber cap of the charging connector in the SIMATE Scooter S6 and connect the
charging adapter "Charging connector No. 9 in the main illustration". Then connect
the charging adapter to your power outlet. When the charging process is finished
and the charging adapter is disconnected, cover the charging connector opening
again with the rubber cap. Regularly check if the protective cap covers the charging
connector whenever the charging does not take place.
CAUTION:
For charging, use only the original accessories supplied with the appli -
ance. When the battery operating time becomes very short, the battery
lifetime has been used up; we recommend that you have the battery re -
placed at your authorized centre. Do not charge your electric scooter in
enclosed spaces and without supervision.
