Before the first start / Setting up the Sencor Scooter K5
1 Handlebar – height adjustable
2 Handlebar height adjustment locking clamp
3 Clamp for attaching handlebar bar to front fork
4 Front wheel with LED effect
5 Electric motor starter
6 Rear mudguard/brake
7 LED effects
8 Scooter body with battery and control unit storage
9 Charging connector
10 Electric motor with LED effect

3. Before First Use

Follow the steps before starting the electric scooter for the first time.
Assemble the electric scooter according to the chapter: Assembling the SIMATE
•
Scooter S6
Adjust the handlebar height correctly.
•
• Check that all nuts and bolts are tightened.Before each ride,check the tightening
and fixing of all detachable parts.If any of the bolts, Allen bolts or nuts are loose,
tighten them with the appropriate tool.
• Charge the battery to full capacity

4. Assembling the SIMATE Scooter S6

a) Attach the handlebars to the bar. The spike on the bar must fit into the handle -
bars. Then cover the handlebar with the to p clamp. The holes for the Allen bolts
must be in one axis. Insert the Allen bolts and tighten them lightly by hand. Fi -
nally, tighten the bolts firmly with the supplied Allen key.
1 – handlebar, 2 – Allen bolt, 3 – clamp, 4 – bar
Copyright © 2023, SIMATE
Before the first start / Setting up the SIMATE Scooter S6
2
1 3
4
EN
M
EN 5
Revision 07/2023
