Technical Specifications

Product Codes
Action Control
Power Requirements
- Running (AC)
- Holding Position (AC)
- Running (DC)
- Holding Position (DC)
Transformer Sizing Requirements
- Minimum per Actuator
Input signal
Auxiliary Switch Rating
(DA-008S230D2 / DA-008S024D2)
Spring Return
Rated Torque
- Power On (Running) 8 Nm at all operating temperatures
- Power Off (Spring Running) 8 Nm at Standard operating temperatures
Rotation Range
Rotation Time for 90°
- Power On (Running) 55 to 71 Seconds for 0 to 8 Nm Load, at All Operating Conditions
- Power Off (Spring Returning) 13 to 26 Seconds for 0 to 8 Nm Load, at Room Temperature
Cycles
Audible Noise Rating
- Power On (Running) <47 dBA at 8 Nm Load, at a Distance of 1 m
- Power On (Holding) <20 dBA at a Distance of 1 m
- Power Off (Spring Returning) <52 dBA at 8 Nm Load, at a Distance of 1 m
Electrical Connections
- Actuator (all models) 1.2 m UL 758 Type AWM Halogen Free Cable with 0.85 mm² (18 AWG) conductors and 6 mm ferrule ends
- Auxiliary Switches (D2 Models) 1.2 m UL 758 Type AWM Halogen Free Cable with 0.85 mm² (18 AWG) conductors and 6 mm ferrule ends
Mechanical Connections
Enclosure Rating
Ambient Conditions
- Standard Operating -20 to 60 °C; 90% RH Maximum, Non-condensing
- Extended Operating -40 to 20 °C; 90% RH Maximum, Non-Condensing
- Storage -40 to 85 °C; 95% RH Maximum, Non-condensing
Shipping Weight
Dimensions
Compliance
2 DA-008S230DX / DA-008S230D2 / DA-008S024DX / DA-008S024D2
DA-008S024DX / DA-008S024D2
ON/OFF
24 V AC at 50/60 Hz (AC 18 V to 30 V)
24 V DC (DC 21.6 V to 28.8 V)
6.1 VA
1.2 VA
3.5 W
0.5 W
7 VA
---
Two Single-Pole, Double-Throw (SPDT), Double-Insulated Switches with Gold Flash Contacts:
AC 24 V, 50 VA Pilot Duty;
AC 240 V, 5.0 A Resistive, 1/4 hp, 275 VA Pilot Duty
Direction is Selectable with Mounting Position of Actuator:
Side A, Actuator Face Away from Damper for CCW Spring Return;
Side B, Actuator Face Away from Damper for CW Spring Return
6 Nm at Extended operating temperatures
Maximum Full Stroke: 95°
Adjustable Stop: 35° to 95° Maximum Position
60 Seconds Nominal at Full Rated Load (0.251 rpm)
21 Seconds Nominal at Full Rated Load
39 Seconds Maximum with 8 Nm load at -20 °C
108 Seconds Maximum with 6 Nm load at -40 °C
60,000 Full Stroke
8 to 16 mm round shaft, or 6 to 12 mm square shaft
IP 54 for All Mounting Orientations
Models: DA-008S024DX / DA-008S024D2: 1.7 kg
Models: DA-008S230DX / DA-008S230D2: 1.9 kg
See figure 1
Distech Controls SAS declares that these products are in compliance with the essential requirements and other relevant provisions
of the EMC Directive and Low Voltage Directive.
DA-008S230DX / DA-008S230D2
230 V AC at 50/60 Hz
(AC 198 to 264 V)
0.04 A
0.03 A
---
---
---
---
