3 Construction

Principal Parts

• Carrier Assembly
• Chassis Assembly
• Distal Dome
• Distal Pyramid
• Distal Tube Clamp
• Patella
• Stanceflex Rubber
• Stanceflex strap
• SmartIP Unit

Component Identification

Carrier Assembly
Distal Dome
Pyramid
Carbon fibre composite & stainless steel
Aluminium alloy, stainless steel, engineering thermoplastic,
fibre reinforced (asbestos free) friction material.
Aluminium alloy
Titanium with stainless steel bolt
Aluminium alloy
Engineering thermoplastic
Natural rubber
Kevlar
Aluminium alloy, stainless steel, Titanium, engineering thermoplastic
Electronic components, batteries
4-Bolt
Patella
Chassis Assembly
5
Stanceflex
Stanceflex Rubber
Batteries
SmartIP Unit
Tube Clamp
Stanceflex Strap
