SANITIZING PROCEDURES
To complete the installation, do the following
sanitizing procedures.
Care is taken at the factory to keep your water
softener clean and sanitary. Materials used to make
the softener will not infect or contaminate your water
supply and will not cause bacteria to form or grow.
However, during shipping, storage, installation and
operation, bacteria could get into the softener. For
this reason, sanitizing as follows is suggested when
installing.
NOTE: Sanitizing is recommended by the
Water Quality Association for disinfecting.
1. Be sure to complete all installation steps, including
programming the control.
2. Pour about 3/4 oz. (1
1
5.25% unscented household bleach (Clorox, Linco,
Bo Peep, White Sail, Eagle, etc.) into the brinewell.
Refer to illustration on page 5.
3. IMPORTANT: Press and hold for 3 seconds
the faceplate TOUCH or HOLD button to start an
immediate recharge. The bleach will be drawn
through the water softener, and out the drain.
This process takes approximately 2 hours.
SPECIFICATIONS/DIMENSIONS
Rated Capacity*
Amount of high capacity resin (lbs/cu. ft)
Resin tank nominal size (in., dia. x height)
Service flow rate (gpm)
Water supply maximum hardness (gpg)
Water supply maximum clear water iron (ppm)**
Water pressure limits (min.-max. psi)***
Pressure drop at rated service flow (psig)
Water temperature limits (min–max °F)
Water supply minimum flow rate (gpm)
Maximum flow rate to drain (gpm)
This system conforms to NSF/ANSI 44 for the specific capacity claims as verified and substantiated by test data.
* Testing was performed using pellet grade sodium chloride as the regenerant salt.
** Extent of iron removal may vary with conditions. The capacity to reduce clear water iron is substantiated
by independent laboratory test data. State of Wisconsin requires additional treatment if water supply
contains greater than 5 ppm clear water iron. Use of Diamond Crystal
will improve iron removal. Refer to Cleaning Iron Out of the Water Softening System section.
*** Canada working pressure limits: 1.4–7.0 kg/cm
Installation Instructions
⁄ tablespoons) of common
2
2 .
4. If, after sanitization, water from the house
faucet tastes salty or has a slight color, this is a
preservative from the resin tank. Turn on the cold
soft water faucets and drain for a few minutes or
until clear.
NOTE: When the sanitizing recharge is over, all
remaining bleach is flushed from the conditioner
and your house COLD water supply is fully soft
immediately. However, your water heater is filled
with hard water and as hot water is used, it will refill
with soft water. When all the hard water is replaced
in the water heater, hot only and mixed hot and cold
water will be fully soft. If you want totally soft water
immediately, after the above recharge, drain the
water heater until the water runs cold.
WARNING:
heater, use extreme care as the hot water could
cause burns. Turn the water heater off prior to
draining.
GXSS20H
7,800 grains with
1.8 lbs. of salt
16,800 grains with
5.8 lbs. of salt
20,000 grains with
9.7 lbs. of salt
31.7/0.61
8 x 40
6.5
50
6
20–125
9
40–120
3
2.0
® Red•Out ® or Super Iron Out ®
12
If you do drain the water
11–1/2"
INLET-OUTLET
18–1/4"
48–3/4"
41–1/4"
3–3/8"
40–1/2"
