Member's Mark M3206ALP Manual De Operación página 7

Parts List for Models M3206ALP & M3206ANG
KEY
Side Burner Gas Valve Assembly (LPG)
47
Side Burner Gas Valve Assembly (NG)
48A Side Burner Connection Hose, Socket
48B Side Burner Connection Hose, Plug
49 Grease Tray
50 Grease Tray Handle
51 Grease Tray Heat Shield, Lower
52 Bowl Support Bracket, Left
53 Bowl Support Bracket, Right
54 Bowl Wind Shield
55 Door Hinge Bracket, Left
56 Door Hinge Bracket, Right
57 Cart Side Panel, Left
Cart Side Panel, Right (LPG)
58
Cart Side Panel, Right (NG)
59 Door Bracket
60 Door Magnet
61 Cart Rear Panel
Cart Bottom Shelf (LPG)
62
Cart Bottom Shelf (NG)
63 Grease Tray Heat Shield, Upper
64 Caster Seat, Left Front
65 Caster Seat, Left Rear
66 Caster Seat, Right Front
67 Caster Seat, Right Rear
68 Caster, 2.5 in., with Brake
69 Door Handle
70 Door, Left
71 Door, Right
72 Regulator with Hose (LPG)
73 Lighting Stick
74 Hose Clip
75 Door Stop Plate
Cart Spice Basket (LPG)
76
Cart Spice Basket (NG)
77 Regulator Assem bly (NG)
78 Side Burner Extension Hose (NG only)
79 Hose, 12ft. (NG)
80 Regulator Bracket (NG)
81 Name Plate
Rotisserie Assembly
Grill Cover
Hardware Pack
Operator's Manual
To obtain the correct replacement parts for your gas grill, please refer to the part numbers in this parts
list. The following information is required to ensure you receive the correct parts:
1. Model and Serial Number (see CSA label on grill)
2. Part Number
3. Part Description
4. Quantity of parts needed
Important: Use only factory authorized parts. The use of any part that is not factory authorized can be
dangerous and will also void your product warranty. Keep this Operator's Manual for convenient referral
and for part replacement.
DESCRIPTION
For the repair or replacement parts you need:
Call our Grill Information Center at
1-800-770-9769
7
PART#
Y0060300
Y0060301
P03705048K
P03705049H
P02707065B
P00213003B
P06903028A
P01301004B
P01302004B
P06906021C
P03302014A
P03302015A
P07602013A
P07603015A
P07603016A
P01316004B
P05523001K
P07701052A
P01008006C
P01008007C
P06903037A
P05327021T
P05327022T
P05327023T
P05327024T
P05110004D
P00205073B
P04302029A
P04303029A
P03601004A
P05507031E
P05536001P
P05510014U
P05204005B
P05204005B
Y0080007
P03705028F
P03703001A
P03328018A
P00414005Q
Y0250089
P07007018A
P06002013A
P80118002H
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
1
4
2
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
