Member's Mark M3206ALP Manual De Operación página 16

Grill Lighting Instructions
1. Before each use, check all hoses for cracks, nicks, cuts,
burns or abrasions. If a hose is damaged in any way, do
not use your grill before replacing the hose with an
authorized part from the Parts List. Also make sure all
gas supply connections are securely tightened.
Familiarize yourself with the safety and Use and Care
2.
instructions in this manual. Do not smoke while lighting
grill or checking gas supply connections.
Be sure the LP Gas tank is filled.
3.
4. Open the Grill Lid.
Check that the end of each Burner Tube is properly
5.
located over each Valve Orifice.
WARNING
!
Failure to replace a faulty hose, secure gas supply
connections or to open the Lid before proceeding
to the Lighting Procedures could result in a fire
or explosion that could cause serious bodily injury,
death, or property damage.
Set Control Knobs to OFF and open the LP Gas
6.
tank valve SLOWLY 1/4 of a turn.
OFF
Push and turn Left Control Knob to HIGH.
7.
LOW
Immediately press the Electric Ignitor for 3-4
8.
seconds to light the Burner.
If ignition does not occur in 5 seconds, turn the
9.
burner Control Knob(s) and gas source OFF and
conduct a leak test of ALL gas connections and gas
sources as explained in the Use and Care section
of this manual. If no leaks are detected, wait 5
minutes for any gas to clear and repeat the lighting
procedure.
After Burner is lit, turn the tank valve SLOWLY one
10.
more 1/4 of a turn for 1/2 of one complete turn.
11. Once one Burner is lit, the adjacent Burner can be lit
by turning its Control Knob to HIGH.
USE AND CARE INSTRUCTIONS
Open LP
gas tank
HI
OFF
PRESS
Burner Control Knobs on Control Panel
Back Burner Lighting Instructions
1.
Follow steps 1 through 6 of the Grill Lighting
Instructions.
2. Push and turn control knob to ON. Immediately
press the Electric Ignitor for 3-4 seconds to light the
!
Burner.
3. If ignition does not occur in 5 seconds, turn the
burner Control Knob(s) and gas source OFF and
conduct a leak test of ALL gas connections and gas
sources as explained in the Use and Care section
of this manual. If no leaks are detected, wait 5
minutes for any gas to clear and repeat the lighting
procedure.
4. After Burner is lit, turn the tank valve SLOWLY one
more 1/4 of a turn for 1/2 of one complete turn.
Side Burner Lighting Instructions
Follow steps 1 through 5 of the Grill Lighting
1.
Instructions.
Open Side Burner Lid.
2.
3. Set Control Knob to OFF and open the LP Gas tank
valve SLOWLY 1/4 of a turn. For Natural Gas open
the Shut Off Valve at source.
4. Push and turn the Control Knob to HIGH. The built
spark ignitor will light the Burner automatically.
5. You may have to pusk and turn the Control Knob up to
3 to 4 times to light.
6. If ignition does not occur, turn the burner Control Knob
and gas source OFF and conduct a leak test of ALL
gas connections and fuel sources. If no leaks are
detected, wait 5 minutes for any gas to clear and re-
peat the lighting procedure.
16
MAIN BACK
BURNER BURNER
ON
OFF
