Parts List for Models M3206ALP & M3206ANG
KEY
1 Lid Assem bly
2 Temperature Gauge
3 Lid Handle
4 Protective Pad
5 Cooking Rack/Secondary
6A Cooking Grid
6B Cooking Grid
7 Burner/Main
8 Savor Plates®
9 Savor Plates® Bracket, Front
10 Savor Plates® Bracket, Rear
11 Burner Bracket
12 Side Shelf, Left
13 Side Shelf Bracket, Left Front/ Right Rear
14 Side Shelf Bracket, Left Rear/ Right Front
15 Bowl Side Panel, Left
16 Bowl Side Panel, Right
17 Grease Draining Plate
18 Back Burner Wind Shield
19 Back Burner Assem bly
20 Back Burner Electrode
Back Burner Orifice (LPG)
21
Back Burner Orifice (NG)
22 Back Burner Extension Tube
23 Bowl Panel, Rear
24 Bowl Panel, Front
25 Lid Hinge
26 Gas Collector Box with Electrode
27 Electric Wire Set
Gas Valve/Manifold Assembly (LPG)
28
Gas Valve/Manifold Assembly (NG)
29 Gas Fitting
30 Control Panel, Upper
31 Control Panel, Extension
Control Panel, Lower (LPG)
32
Control Panel, Lower (NG)
33 Control Knob Seat
34 Control Knob Spring
35 Control Knob for Main Burners
36 Control Knob for Back Burner
37 Electric Ignitor, 6-port
38 Side Burner Lid
39 Side Burner Frame
40 Side Burner Body
41 Side Burner Pot Support
42 Side Burner
43 Side Burner Electrode
44 Control Knob for Side Burner
45 Control Knob Spring
46 Control Knob Seat for Side Burner Knob
DESCRIPTION
6
PART#
Y0110038
P00601061A
P00205069B
P05518002I
P01516003A
P01604012A
P01604010A
P02008024A
P01708004A
P03328015A
P03328017A
P0220505ED
P01106005A
P01204005F
P01206005F
P0072054PC
P0072154PC
P06902005C
P06905037B
Y0310023
P02610005B
P06527003A
P06527004A
P03717024B
P0072555DC
P0073855DC
P05501020A
P02609002B
P02615080A
Y0060297
Y0060298
P03906003A
P02909198S
P02909401S
P02909211A
P02909221F
P03415014S
P05504021A
P03411383S
P03411373S
P02502145C
P01127004B
P01104010A
P02301015B
P00805010B
P02002012A
P02614007C
P03401043S
P05504021A
P03408053S
QTY
1
1
1
4
1
2
1
5
5
5
5
1
1
2
2
1
1
2
1
1
1
1
1
1
1
1
2
5
1
1
1
1
1
1
1
1
6
6
5
1
1
1
1
1
1
1
1
1
1
1
