2) The power mixer can
be rested against the rim
of the container but must
be tilted so that it does
not touch the bottom of
the container.
3) If using the power
mixer support (optional
accessory), on the top of
the container, the power
mixer should be positio-
ned in the middle of the
support and at a slight
angle.
Do not operate the
power mixer with the bell straight up-and-down
against the bottom of the container
4) The splashguard should always be in place.
5) For optimum efficiency two thirds
should be immersed in the product.
6) Always make sure that the bell is completely
immersed to avoid splashing and that the ventilation
openings in the motor housing do not come into
contact with any liquid !
• WHISK FUNCTION
We recommend that you
hold the power mixer
by the handle and the
bottom of the motor unit.
You can also hold the
appliance by the handle
with one hand, leaving
the other hand free
to hold the bowl, if
necessary.
While processing we
recommend that you
move the whisk around
in the bowl, in order
to ensure that the
mixture is completely
homogeneous.
We strongly advise you
to keep the whisk from
touching the sides of
the bowl. For maximum efficiency, at least one-fifth
POWER MIXER
of the whisk length should be immersed. We also
ON THE PAN
SUPPORT
strongly advise you to start the processing at a low
speed.

ASSEMBLY/DISASSEMBLY

• BLADE FUNCTION
Attaching the tube to the motor unit,
(Except for MP 350 Turbo, MP 450 Turbo,
MP 550 Turbo, MP 600 Turbo).
2 / 3 of the tube
- Unplug the power mixer.
- Unplug the machine then, align the flat side of
the conical part
the aluminum casing.
- Insert the narrow portion of conical part
tube into the aluminum casing.
- Turn the tube in the direction of the arrow (see
figure) until it is snugly in place.
A
of the tube with catch in
C B
of the
C
Removing the tube from the casing
- Unplug the power mixer.
- Turn the tube in the opposite direction of that used
to attach it.
- When it will not go any further, remove the tube
from the conical part.
Attaching the bell to the tube
TURN TO
ATTACH BELL
- Unplug the power mixer.
- Align the flat side of A the conical part of the
tube with catch on the inside of the bell.
B
- Insert the conical part into the bell. With the
C
washer touching the tube seal
D
the direction of the arrow (See figure) to lock the
bell lug and tube lug snugly together.
E F
Disassembling the bell from the tube
TURN TO REMOVE BELL
, turn the bell in
