INTRODUCTION TO YOUR
NEW ROBOT-COUPE
POWER MIXER
Robot-Coupe has developed a complete line of
power mixers. The features of each are described in
the table below.
Variable
Models
Speed
MP 350 Turbo
MP 350 Turbo V.V.
MP 450 Turbo
MP 450 Turbo V.V.
MP 550 Turbo
MP 600 Turbo
MP 350 Turbo Combi
MP 450 Turbo Combi
MP 450 Turbo FW
The Robot-Coupe Power Mixers perform a host of
culinary feats. The mixer attachment will allow you
to make soups, vegetable purees and pulps while
the whisk attachment is ideal for making pancake
batter, mayonnaise, beaten egg whites, chocolate
mousse, butter sauces, whipped cream or smooth
fromage frais.
The variable speed function will enable you to
adjust the speed to suit each preparation and to
start the processing at a lower speed in order to
reduce splashing.
The power mixer is easily assembled and disassem-
bled for maintenance and cleaning.

OPERATING THE POWER MIXER

OPERATION
The power mixer is equipped with electrical current
and temperature overload protection. If the power
6
mixer stops unexpectedly you may try to restart it
by following steps 3-5 below. If the power mixer
does not restart, allow it to cool for a period of up
to 30 minutes and the temperature overload will
automatically reset. You should then be able to
restart following steps 3-5 below.
1. Check that the control button
(CB) is in the released position.
Mixer
Whisk
2. Connect the cord to the
attachment
attachment
power supply
3. Put the tube into the product
with the bell completely
immersed and the splash guard
in place.
4. Press and hold down the
safety button (SB).
5. Press the control button (CB)
and the power mixer will start.
6. Release the safety button (SB).
7. To stop the power mixer,
release the control button (CB).

• CONTINUOUS OPERATION

8. Follow steps 1-6 above,
then : While the control
button (CB) is pressed, press
the locking button (LB).
9. Release the control button
(CB).
10. Release the locking
button (LB), and the power
mixer will run continuously.
11. To stop the power mixer,
press and release the
control button (CB).
• VARIABLE-SPEED OPERATION
Follow steps 1 to 6 above, then change the speed of
the motor by turning the button (VS) toward the
maximum or minimum as required.
It is advisable to start at a low speed when using
the whisk.
Principal of automatic speed regulation : Once you
SB
VS
have selected the right speed, allow the mixer to run
CB
LB
on it's own. The speed will remain the same, even if
the consistency of the product changes.
• MASHED POTATOES FUNCTION
(MP 350 Turbo Combi, MP 450 Turbo Combi,
MP 450 Turbo FW).
speed variation switch indicates the speed dedicated
to mashed potatoes preparation.To reach this
speed, turn the knob counterclockwise until it stops
(irregular rotating movement).
• BLADE FUNCTION
1) Hold the power mixer
firmly by the handle and
the bottom of the motor
base and tilt it at a slight
angle. Move the mixer
around in the container
for complete processing.
A self-regulating speed
system has been specially
developped for pureeing tasks
using the whisk.
A triangle marked on the

WORKING POSITION
