Metabo KFM 9-3 RF Instrucciones De Manejo página 9

Always hold the machine with both hands on the
intended handles, take a secure stance and
concentrate on the work.
Keep your hands away from the milling area and
from the tool.
Do not touch the rotating tool! Remove chips and
similar material only with the machine at a standstill.
Press the spindle locking button (2) only when the
motor is off.
Damaged, eccentric or vibrating tools must not be
used.
Do not work overhead.
Additional Warnings:
Some dust created by power
sanding, sawing, grinding,
drilling, and other construction activities
contains chemicals known to cause cancer,
birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and
other masonry products, and
• Arsenic and chromium from chemicallytreated
lumber.
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well
ventilated area, and work with approved safety
equipment, such as those dust masks that are
specially designed to filter out microscopic
particles.
3.3 Special safety instructions for mains
powered machines:
Pull the plug out of the socket before making any
adjustments, changing tools, carrying out
maintenance or cleaning.
Use of a fixed extractor system is recommended.
Always install an RCD / GFCI with a maximum trip
current of 30 mA upstream. When the machine is
shut down by the RCD / GFCI, it must be checked
and cleaned. See chapter 9. Cleaning.
3.4 Special safety instructions for cordless
machines:
Remove the battery pack from the machine before
making any adjustments, changing tools,
maintaining or cleaning.
Protect battery packs from water and
moisture!
Do not expose battery packs to fire!
Do not use faulty or deformed battery packs!
Do not open battery packs!
Do not touch contacts or short-circuit battery packs!
A slightly acidic, flammable fluid may leak
from defective Li-ion battery packs!
If battery fluid leaks out and comes into
contact with your skin, rinse immediately
California Prop 65 08_2018
with plenty of water. If battery fluid leaks out and
comes into contact with your eyes, wash them with
clean water and seek medical attention
immediately!
If the machine is defective, remove the battery pack
from the machine.
Transport of li-ion battery packs:
The shipping of li-ion battery pack is subject to laws
related to the carriage of hazardous goods (UN
3480 and UN 3481). Inform yourself of the currently
valid specifications when shipping li-ion battery
packs. If necessary, consult your freight forwarder.
Certified packaging is available from Metabo.
Only send the battery pack if the housing is intact
and no fluid is leaking. Remove the battery pack
from the machine for sending. Prevent the contacts
from short-circuiting (e.g. by protecting them with
adhesive tape).
SYMBOLS ON THE TOOL:
.......... Class II Construction
V ............. volts
A ............. amperes
Hz ........... hertz
.../min...... revolutions per minute
~ ............. alternating current
............ alternating current /direct current
n ............. rated speed
The "C" and "US" indicators adjacent to the
CSA Mark signify that the product has been
evaluated to the applicable CSA and ANSI/
UL Standards, for use in Canada and the U.S.,
respectively.
4. Overview
See page 2.
1 Clamping screws
2 Spindle locking button
3 Bow handle
4 Wing nuts
5 Slide switch
6 Handle
7 Speed adjustment wheel
8 Dust filter *
9 Battery pack release button *
10 Battery pack *
11 Capacity indicator button *
12 Capacity and signal indicator *
13 Electronic signal indicator *
14 Graduated collar
15 Adjusting ring
16 Scale
17 Knurled screw *
18 Ripping fence*
19 Support surface
20 Screw for fixing the ball bearing stationary seal
ring
21 Ball bearing stationary seal ring
22 Indexable insert
23 Fastening screw
24 Holder for indexable insert
ENGLISH en
9
