This Owner's Manual is provided and hosted by Appliance Factory Parts.
HOOVER U8187-900
Owner's Manual
Shop genuine replacement parts for HOOVER
U8187-900
Find Your HOOVER Vacuum Cleaner Parts - Select From 1455 Models
-------- Manual continues below --------
Tabla de contenido
loading

Manuales relacionados para Hoover U8187-900

Resumen de contenidos para Hoover U8187-900

  • Página 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. HOOVER U8187-900 Owner's Manual Shop genuine replacement parts for HOOVER U8187-900 Find Your HOOVER Vacuum Cleaner Parts - Select From 1455 Models -------- Manual continues below --------...
  • Página 2 Please review this manual before o ©2008 Healthy Gain Investments, Ltd...

  • Página 3: Tabla De Contenido

    Parts & accessories mail order form .........19 If you need assistance: Visit our website at hoover.com. Follow the service center link to find the service outlet nearest you OR Call 1-800-944-9200 for an automated referral of authorized service outlet locations (U.S.
  • Página 4 • Do not use with damaged cord or plug. If ap dropped, damaged, left outdoors, or dropped Service Center or Authorized Hoover Warrant • Do not pull or carry by cord, use cord as a han sharp edges or corners. Do not run appliance o •...

  • Página 5: Assembling Cleaner

    1. Assembling cleaner Cleaner assembly Carton contents Empty carton. Find the parts shown below before disposing of packing materials. Disconnect cleaner from electrical outlet. Remove cardboard (A) and four screws from handle section. Discard cardboard, but keep screws for assembly (Figs. 1-6 and 1-7). A.

  • Página 6: How To Use

    2. How to use Cleaner description Operate cleaner only at voltage specified on data plate on bottom of cleaner. The assembled cleaner will look like the drawing. 1. Handle 2. Custom Control™ powerswitch 3. Custom Control™ indicator 4. Tool cover 5.

  • Página 7: Custom Control™ Switch

    Custom Control™ switch Plug cord into electrical outlet. CARPET setting - turns brush roll on, for cleaning carpets and rugs. (Brush roll will automatically stop turning when handle is raised to upright position.) BARE FLOOR setting - turns brush roll OFF for clean- ing hard surfact floors.

  • Página 8: Cleaning Lightweight Flexible Rugs

    Cleaning lightweight flexible rugs Cleaning tools When using cleaning tools, cleaner handle should be in the upright position to activate the automatic “brush roll automatic shut off” and for convenience in moving the cleaner from one area to another. 2.10 Turn cleaner OFF before disconnect- ing and connecting...

  • Página 9: Stair Cleaning

    Attach wand and tools How to clean tools To clean the hose and the powered hand 2.12 tool, wipe off dirt with a cloth dampened in a mild detergent. Rinse with a damp cloth. Do not submerge powered hand tool in water.
  • Página 10 3. Maintenance Familiarize yourself with these home main- tenance tasks. Proper use and care of your cleaner will ensure continued cleaning effectiveness. Dirt cup When to empty We recommend that the dirt cup be emp- tied before the dirt reaches the dirt opening on back of cup (Fig.

  • Página 11: Filter Assembly

    Filter assembly How to clean filter assembly The HEPA cartridge filter and pre-filter are Remove dirt cup essentially self-shedding. and dirt cup lid as Tapping the side of the dirt cup as described described in “How in “How to empty dirt cup” should suffi- to empty dirt cup.”...

  • Página 12: Filter Bag

    Filter bag When to replace Check filter bag from time to time. It is rec- ommended that you replace the filter bag before debris reaches the bottom of the bag collar. If more dirt than this accumulates, your cleaner will not operate effectively. Note: All new carpet has loose fibers which can fill the bag quickly while vacuuming.
  • Página 13 Headlight replacement What to buy This cleaner uses a 12 volt, wedge base type 912 bulb, Hoover part No. 27313107. Disconnect cleaner 3.17 3.16 from electrical outlet. Step on handle release pedal and place cleaner in the lowest position. Turn cleaner over.

  • Página 14: Belt Replacement

    Belt replacement The belt on your Hoover cleaner causes the brush roll to rotate and is important for the effective operation of your cleaner. The brush roll belt is designed to last a long time and does not normally need replacement.

  • Página 15: Powered Hand Tool

    A new belt can be installed at your nearest Hoover Sales and Service Center. Powered hand tool Agitator brush roll replacement When agitator brushes are worn, the brush roll should be replaced. Ask for HOOVER part No. 48414150. 2. Unscrew the two 3.30 3.31 3.32...
  • Página 16 Pivot bottom plate down and snap closed. Replace belt When replacing 3.37 belt, ask for HOOVER part No. 38528037. 1. Remove bottom plate, belt guard and brush roll as described in Figs. 3-27 through 3-29. 2. Grasp turbine (E) and pull firmly to remove.

  • Página 17: If You Have A Problem

    Thermal protector An internal thermal protector has been 3. Refer to “Clearing blockages” section. designed into your cleaner to protect it from 4. When the motor cools, the thermal overheating. protector automatically resets and cleaning When the thermal protector activates, the may continue.

  • Página 18: Clearing Blockages

    PROBLEM POSSIBLE CAUSE Cleaner hard to Incorrect carpet height set- push ting Broken or worn belt Cleaning tools Blockage in hose won’t pick up Visible dirt Filter assembly not installed leaking through properly final filter Dirt inside dirt cup stops spinning Powered hand Too much pressure being...
  • Página 19 • calling 1-800-944-9200 for an automated referral of authorized service outlet loca- tions (U.S. only). Do not send your cleaner to Hoover, Inc., Company in Glenwillow for service, this will only result in delay.
  • Página 20 Name on Card ________________________ Signature (req.) _______________________ Replacement parts and accessory items may be purcha Retailers, Hoover Sales & Service Centers, on-line at ww Mail orders limited to U.S. residents only. In Canada, pl Please allow 3-4 weeks for delivery.

  • Página 21: Parts And Accessories

    Parts and Accessories RETAIN THIS SECTION FOR YOUR RECORDS Item Part Qty/ Price/Pk. Qty. Total Description HEPA Cartridge Filter 40140201 $ 24.99 HEPA Filtration Type Y Disposable Filter Bags 4010801Y $ 9.99 Allergen Filtration Type Y Disposable Filter Bags 4010100Y $ 9.99 Final Filter 40110009...

  • Página 22: Piezas Y Accesorios

    Piezas y Accesorios CONSERVE ESTA SECCIÓN PARA SUS EXPEDIENTES Desprenda esta sección y envíela por correo a: Hoover, Inc. 7005 Cochran Road • Glenwillow, Ohio • 44139 Attn: Sales & Service Center Descripción N.° Cant./ Precio/ Cant. Total del artículo de pieza Paq.

  • Página 23: Formulario Para P

    Número _____________________________ Si necesita ayuda: Visite nuestro sitio web en hoover.com. Siga el enlace del centro de servicio para encontrar el Nombre en la tarjeta ___________________ centro de servicio más cercano o llame al 1-800-944-9200 para que le informen de manera automática las ubicaciones de los centros autorizados de servicio (únicamente en los EE.

  • Página 24: Lea Todas Las Instrucciones

    • No aspire ningún objeto que se esté quemando o qu Para obtener un servicio aprobado de No envíe su aspiradora a Hoover, Inc., calientes. HOOVER y piezas de HOOVER genuinas, Company en Glenwillow para realizar el •...

  • Página 25: Ensamblado De La Aspiradora

    1. Ensamblado de la aspiradora PROBLEMA CAUSA POSIBLE Es difícil empujar Ajuste incorrecto de la altura Contenido de la caja Ensamblado de la aspiradora para alfombras la aspiradora Correa rota o desgastada Vacíe la caja. Encuentre las piezas que se muestran a continuación antes de desechar Los accesorios Obstrucción en la manguera...

  • Página 26: Si Tiene Un Problema

    2. Modo de uso Protector térmico Su aspiradora tiene incorporado un protector 3. Consulte la sección “Eliminación de Descripción de la aspiradora térmico para impedir el sobrecalentamiento. obstrucciones”. Haga funcionar la aspiradora para alfombras Cuando el protector térmico se activa, el 4.

  • Página 27: Ajuste De La Altura De La Alfombra

    38528037 hacia atrás, sobre las funcionamiento, para uso general sobre No levante la de HOOVER. ruedas traseras. alfombras de pared a pared y pisos; baja, para aspiradora por el Empújela hacia aspirar debajo de muebles de poca altura. Pise 1.

  • Página 28: Accesorio De Mano Turboaccionado

    Cuando las escobillas del agitador están desgastadas, debe reemplazarse el rodillo de posición vertical para activar el “apagado escobillas. Solicite la pieza n.° 48414150 de HOOVER. automático del rodillo de escobillas” y para 2. Desatornille que resulte más cómodo mover la aspiradora...

  • Página 29: Manguera Con Alcance Adicional Extra Reach

    Conecte los tubos o accesorios al otro extremo de la manguera. Reemplazo de la correa Cómo colocar la tapa de accesorios La correa de su aspiradora Hoover hace La tapa de accesorios ha sido diseñada con una que el rodillo de escobillas gire y es 2.16 función “desprendible”...

  • Página 30: Reemplazo De La Luz Delantera

    Voltee la Voltee la aspiradora. Retire el emblema aspiradora. Usando HOOVER® (B). Con un destornillador un destornillador Phillips, retire el tornillo (C) que se Phillips, retire los encuentra debajo del emblema. en la parte posterior...

  • Página 31: Conjunto Del Filtro

    Conjunto del filtro Bolsa de filtro Cómo limpiar el conjunto del filtro Cuándo reemplazarla El filtro del cartucho HEPA y el prefiltro Retire el depósito permiten que la suciedad se desprenda para polvo y la tapa Revise la bolsa de filtro periódicamente. Se del depósito para fácilmente.
