Pump Control KI-04 Manual Del Usuario página 14
Tabla de contenido
CPUKI04
B1
B2
CONNECTOR : B1
TYPE : TERMINAL BLOCK-4
1 - HOT 220V AC ( BROWN )
2 - NEUTRAL ( LIGHT BLUE )
3 - EARTH ( GREEN-YELOW )
4 - NC
4
3
2
1
E
U
L
B
N
W
T
W
Y
H
-
O
G
R
R
I
L
B
G
SINGLE
PHASE
INPUT
CPUKI04
B1
B2
T O P V I E W
T E R M I N A L B L O C K
WIRE : 0.75mm
SOLENOID
VALVE
LOW
*
SOLENOID
VALVE
HIGH
* O P T I O N A L
CONNECTOR : B1
TYPE : TERMINAL BLOCK-2
1 - +12/24V DC INPUT ( RED )
2 - 0V GND INPUT ( BLACK )
1
2
K
C
D
A
E
L
R
B
12/24V DC INPUT
CONNECTOR : B2
TYPE : TERMINAL BLOCK-4
1 - HOT RELAY OUTPUT ( RED )
2 - NEUTRAL RELAY OUTPUT ( RED)
3 - HOT SOLENOID VALVE OUTPUT ( WHITE )
4 - NEUTRAL SOLENOID VALVE OUTPUT ( WHITE)
4
3
2
1
E
E
T
T
I
I
D
D
H
H
E
E
W
W
R
R
*
*110/220VCA CO
LS
I
FOR VERSION OF
KI04 AND USING
SINGLE PHASE INPUT
*
DESCRIPTION
www.pump-control.com
Wire connections KI-04 : AC POWER INPUT-OUTPUT
dptotecnico@pump-control.com
FOLDER
FI LE
Cxxxxx
CON-KI04
P A G E
No part of this information may be reproduced without
1/1
the prior written consent of PUMP CONTROL SRL
T O P V I E W
T E R M I N A L B L O C K
LOW
SOLENOID
VALVE
DESCRIPTION
www.pump-control.com
INTERNAL WIRING DIAGRAM - DC POWER INPUT AND VALVES OUTPUT
dptotecnico@pump-control.com
FOLDER
FI LE
Cxxxxx
CON-KI04
P A G E
No part of this information may be reproduced without
1/1
the prior written consent of PUMP CONTROL SRL
RELAY
MOTOR
Guaminí 2062/64 (C1440 ESN) Bs.As. Argentina
PART NUMBER
RE V
XXX
3
DESIGNED
FF
CONNECTOR : B2
TYPE : TERMINAL BLOCK-4
1 - +VDC LOW VALVE ( RED )
2 - ENABLE 0V GND LOW VALVE ( WHITE )
3 - +VDC HIGH VALVE ( RED )
4 - ENABLE 0V GND HIGH VALVE ( BROWN )
1
2
3
4
N
E
T
W
I
D
D
O
H
E
E
R
W
B
R
R
*
HIGH
SOLENOID
VALVE
* O P T I O N A L
12/24V DC COILS DEPENDING ON
KI04 VDC INPUT
Guaminí 2062/64 (C1440 ESN) Bs.As. Argentina
PART NUMBER
RE V
XXX
1
DESIGNED
FF
3 PHASE
INPUT
D A T E
28/09/06
AP P ROVE D
CP
D A T E
28/07/09
AP P ROVE D
CP
