Pump Control KI-04 Manual Del Usuario página 13

PC ITRS232LP
CPUKI04
B1 B2
CONNECTOR : B1
TYPE : TERMINAL BLOCK-4
1 - HOT 220V AC ( BROWN )
2 - NEUTRAL ( LIGHT BLUE )
3 - EARTH ( GREEN-YELOW )
4 - NC
4 3 2 1
E
U
L
B
N
T
W
W
Y
H
-
O
G
R R
I
L B
G
SINGLE
PHASE
INPUT
COMMUNICATION
PRINTER
NOZZLE
SWITCH
T O P V I E W
T E R M I N A L B L O C K
WIRE : 0.75mm
SOLENOID
VALVE
LOW
*
SOLENOID
VALVE
HIGH
* O P T I O N A L
KI-04
PULSER
DESCRIPTION
www.pump-control.com
Wire connections KI-04
dptotecnico@pump-control.com
FOLDER FI LE
Cxxxxx CON-KI04
P A G E No part of this information may be reproduced without
1/1 the prior written consent of PUMP CONTROL SRL
CONNECTOR : B2
TYPE : TERMINAL BLOCK-4
1 - HOT RELAY OUTPUT ( RED )
2 - NEUTRAL RELAY OUTPUT ( RED)
3 - HOT SOLENOID VALVE OUTPUT ( WHITE )
4 - NEUTRAL SOLENOID VALVE OUTPUT ( WHITE)
4 3 2 1
E E
T T
I I
D D
H H
E E
W W
R R
*
*110/220VCA CO LS
I
FOR VERSION OF
KI04 AND USING
SINGLE PHASE INPUT
*
DESCRIPTION
www.pump-control.com
Wire connections KI-04 : AC POWER INPUT-OUTPUT
dptotecnico@pump-control.com
FOLDER FI LE
Cxxxxx CON-KI04
P A G E No part of this information may be reproduced without
1/1 the prior written consent of PUMP CONTROL SRL
SOLENOIDE
RELAY
VALVE
TEMPERATURE
SENSOR
Guaminí 2062/64 (C1440 ESN) Bs.As. Argentina
PART NUMBER RE V
XXX 2
D ES IG NE D
FF
RELAY
MOTOR
Guaminí 2062/64 (C1440 ESN) Bs.As. Argentina
PART NUMBER RE V
XXX 3
DESIGNED
FF
MOTOR
D A T E
28/09/06
A P P R OV E D
CP
3 PHASE
INPUT
D A T E
28/09/06
AP P ROVE D
CP
